Precaution for synchronization
Some PABX having several ISDN lines which are not able to ensure synchronization on the various lines
with a simple configuration.
The marks of PABX concerned known to date are: Alcatel, Ericsson and Siemens.

1.3 Link Gate Router

The gate is provided with ISDN input. The cable leading from this input must be connected to the former
ISDN line (exchange line). The other connector (output ISDN line) is used as a standard ISDN line
(connection to the exchange).
In this way, the user does not lose the former IDSN line. After proper LCR setting, the selected calls are
routed in GSM networks; the other calls pass further in the former ISDN line. The incoming calls are merged
from both directions in the ISDN output.
1.4 Optional m odules
Some modules are now available for the GSM Link Gate ISDN:
a) OGM module
Recording available with the software provide or through an ISDN phone.
10 seconds recording (see p 16)
b)
.
SMS Server
Send and received SMS through POP mail software. (For more details see SMS server manual. (p 21)
c) Remote configuration
Remote control of the Gateway, with a SIM card having data option.

1.5 Package content

1 gateway Link Gate ISDN 1
1 magnetic antenna
1 SIM card holder
1 power supply
1 installation CD
1 RS 232 cable
1 RJ 45 / RJ 45 cable for sy nchronization
1 T f or RJ 45
Ce document est la propriété de Linkcom.
Toute reproduction même partielle est strictement interdite
ISDN 1
classe
DR
ISDN 2
1 gateway Linkgate ISDN 2
2 magnetic antennas
2 SIM card holders
1 power supply
1 installation CD
1 RS 232 cable
1 RJ 45 / RJ 45 cable for sy nchronization
1 T f or RJ 45
numéro
classement
LGISDNeng 6.5
002.02
date
page
09/11/04
4/22
