4.5.2.
Search the audio file
Adaptator« Série-Jack »
4.5.3.
The quality w ill be better than through a nor mal phone, and also it w ill be easier to mix voice
and music before recording it on the module.
4.6

ISDN parameters selection

Point to Point ( PPP) & Point to Multipoint ( PTMP)
The telephones connected to the GSM gate mostly do not include a pushbutton for
establishing connection by the dialled number as GSM telephones. This "defect" is by-passed
by selecting a fixed number of digits after which sending of the dialled number ( max. digits
parameter here) takes place in case of GSM gates. Sending the number if another digit is not
selected w ithin the preset time (w aiting parameter here) period is another w ay. Of course,
both parameters can be combined in a suitable w ay. The gate supports transfer of CLIP from
the GSM netw ork in ISDN, i.e. to a telephone connected to an extension (if the device allow s
it). Here it is advantageous to use the parameter for deleting the initial digits from CLIP (e.g.
deleting +42 in order not to "confuse" LCR exchanges w hen calling back to the displayed
number).
Ce document est la propriété de Linkcom.
Toute reproduction même partielle est strictement interdite
Record w ith OGMRec software and « serial-jack » adaptor

Benefits of the software

classe
DR
Name of the audio file 1
Percent of memory used by
module
Stop record
Rec button for 2nd module
Rec button for 1st module
numéro
classement
LGISDNeng 6.5
002.02
date page
09/11/04 14/22
