USB 3.0 to AC1200 Dual Band Wireless-AC
Network Adapter - 802.11b/g/n/ac
USB867WAC22
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 03/04/2014
*actual product may vary from photos

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USB867WAC22 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for StarTech.com USB867WAC22

Summary of Contents for StarTech.com USB867WAC22

  • Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 03/04/2014...

  • Page 2: Fcc Compliance Statement

    (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by StarTech.com could void the user’s authority to operate the equipment.
  • Page 3 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...

  • Page 4: Table Of Contents

    Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Product Overview ..................1 Installation ....................2 Windows ............................... 2 Mac OS ................................3 Verifying Installation ................3 Windows ............................... 3 Mac OS ................................4 Operation ....................4 Windows ..............................4 Specifications ..................22 Technical Support ..................23 Warranty Information ................23...

  • Page 5: Introduction

    Introduction Packaging Contents • 1 x USB Wireless Adapter • 1 x Driver CD • 1 x Instruction Manual System Requirements • Available USB port Product Overview Link/Activity LED WPS Button USB 3.0 LED Indicator Off – No power to adapter On / Blinking –...

  • Page 6: Installation

    Installation Windows 1. Insert the provided CD into your DVD/CD-ROM drive. 2. Select Autorun.exe from the Autoplay menu. If Autoplay is disabled on your system, browse to your CD/DVD drive and run the application. 3. Select the Driver Installation option. 4.

  • Page 7: Mac Os

    Mac OS 1. Insert the provided CD into your DVD/CD-ROM drive. 2. Browse to the appropriate Mac OS version folder on the disc and run the Installer. pkg application to start the install. 3. Follow the on-screen instructions to complete the installation. NOTE: You may be prompted to restart once the install completes.

  • Page 8: Mac Os

    Mac OS 1. Open the System Report by clicking the Apple symbol in the top left corner, selecting About this Mac, then select System Report 2. Expand the “Hardware” section and click “USB” in the left column. With the adapter connected, you should see the following device in the list.

  • Page 9: Realtek Utility

    Move the cursor to the upper right corner to open the Charms Windows 8 Bar, select Settings and then select Wifi Windows 7 Click the network adapter tray icon Windows Vista Click Start, then Connect To Right-click the wireless adapter tray icon and select View Windows XP Available Wireless Networks Realtek Utility...
  • Page 10 General Tab Displays information related to the currently connected network. Signal Strength – Strength of the link between the adapter and the connected AP. Link Quality – Measurement of transmit / receive performance over the radio. Renew IP button – Refresh IP settings between the adapter and the connected AP Instruction Manual...
  • Page 11 Profile Tab Add, Remove, Edit, Duplicate or Set Default wireless profiles. Instruction Manual...
  • Page 12 Available Networks Tab Displays a site survey of networks within range of the adapter. Refresh – Rescan for available networks. Add to Profile – Select a network from the list and click to create a profile for that network. Instruction Manual...
  • Page 13 Status Tab Displays networking and device driver version details for the adapter. Instruction Manual...
  • Page 14 Statistics Tab Displays connection transmit / receive statistics. Reset – Resets all counters. Instruction Manual...
  • Page 15 WPS Setup Tab Allows for WPS PIN code or Push-button modes. Access Point Mode The device can also act as a Wireless Access Point, allowing other devices to connect and gain Internet access through it. Switch modes using the Mode menu at the top of the interface: Instruction Manual...
  • Page 16 General Tab Displays general information about the device in AP mode and a list of joined APs. SSID - The network name of this AP. BSSID - The MAC address of this AP. Association Table Displays the list of joined stations to this AP. AID (Association ID) –...
  • Page 17 Config – Opens a dialog of for modifying AP settings (shown below). ICS (Internet Connection Sharing) - Enables this AP to share this internet/intranet network connection. Network Name (SSID) - The network name of the AP, searchable by other wireless nodes.
  • Page 18 Advanced Tab Provides advanced configuration options for the AP. Beacon Interval – The frequency at which the beacon packet is sent, In TU unit (1024 micro-seconds). DTIM Period - The number of Beacon intervals between successive DTIMs. Preamble Mode: Long - Higher quality but with lower performance than preamble short mode. Short - Normal quality but with higher performance then preamble long mode.
  • Page 19 Statistics Tab Displays connection transmit / receive statistics. Instruction Manual...
  • Page 20 Mac OS Link Status Tab Displays information related to the currently connected network. Signal Strength – Strength of the link between the adapter and the connected AP. Radio Off – Disable the wireless radio. Instruction Manual...
  • Page 21 Profiles Tab Add, Remove, Edit, Duplicate or Set Default wireless profiles. Instruction Manual...
  • Page 22 Available Networks Tab Displays a site survey of networks within range of the adapter. Instruction Manual...
  • Page 23 Advanced Settings Tab Provides advanced configuration options for the device. Preamble Mode: Long - Higher quality but with lower performance than preamble short mode. Short - Normal quality but with higher performance then preamble long mode. Auto - Select the proper preamble mode by current signal frame information. QoS Mode –...
  • Page 24 WPS Tab Allows for WPS PIN code or Push-button modes. Instruction Manual...
  • Page 25 Information Tab Displays utility and driver version information. Instruction Manual...

  • Page 26: Specifications

    Specifications Host Interface USB 3.0 Chipset Realtek - RTL8812AU External Connectors 1 x USB 3.0 A Male IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, Supported Standards IEEE 802.11n, IEEE 802.11ac Draft 2.0 Antenna Configuration 2x2:2 (TxR:S) 2.400GHz ~ 2.484GHz Wireless Frequencies 5180GHz ~ 5805GHz Supported Security Schemes 64/128 bit WEP, WPA, WPA2 (TKIP/AES)

  • Page 27: Technical Support

    Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
