Instrument Components

1. Projector Head
2. Projection Lens
3. Remote Detection Window
4. Remote Control Unit
5. Mounting Bracket
6. Clamp-down Screw
7. Power Switch
8. Fuse Compartment with Voltage Indicator
9. Power Input
10. Halogen Bulb Housing
11. Chart Focusing Control
12. Distance Focusing Control
13. RS232C Serial Port
13800-101-Rev. E
1
2
3
4
5
6
7
13
8
9
10
11
12
5
