- Page 1 ® LongLife P-O-C User’s Guide...
- Page 2 ©2009 Reichert, Inc. Reichert is a registered trademark of Reichert, Inc. The information contained in this document was accurate at time of publication. Speciications subject to change without notice. Reichert, Inc. reserves the right to make changes in the product described in this manual without notice and without incorporating those changes in any products already sold.
-
Page 3: Table Of Contents
Table of Contents Warnings & Cautions ..................... 4 Symbol Information....................5 Package Contents ....................6 Instrument Components ..................6 Installation And Alignment ..................7 Slide Selection ....................... 9 Bulb Life......................... 9 Filament Alignment ....................9 Internal Fuse......................9 Bulb Replacement ....................10 Slide Cleaning ..................... -
Page 4: Warnings & Cautions
WARNING: AN INSTRUCTION THAT DRAWS ATTENTION TO RISK OF INJURY OR DEATH. WARNING: ANY REPAIR OR SERVICE TO THE L POC MUST BE PERfORMED BY EXPERIENCED PERSONNEL OR DEALERS THAT ARE TRAINED BY REICHERT SO THAT CORRECT OPERATION Of THE L POC IS MAIN- TAINED. -
Page 5: Symbol Information
Symbol Information The following symbols appear on the instrument. Caution symbol indicating important operating and maintenance instructions that are included in this User’s Guide. Type B Product Classiication. Class 1 Equipment, Continuous Operation. Alternating Current Power. Protective Earth Connection. ON / OFF. Date of Manufacture. -
Page 6: Package Contents
Contents of the shipping container should include 7. Variable Focus Objective Tube the following: 8. Outer Objective 9. Inner Objective 1 LongLife P-O-C™ Head 10. Retaining Ring (See Instrument Components for 11. Outer Objective Tube Locking Screw detailed listing.) 12. Inner Objective Tube Locking Screw 1 Objective Tube 13. -
Page 7: Installation And Alignment
(11) and (12) to provide freedom of inches (240 inches x .014545 = 3.49 inches) movement. 6. Attach the LongLife P-O-C head to the mount 3. Determine the refracting distance by measur- by unscrewing the mounting knobs (5) insert- ing the head into the yoke (17) and reitting the ing the distance from the patient to the screen. - Page 8 Screen Spot of Light on Wall Patient FIGURE 3 Screen LETTER SIZING CHART REFRACTING DISTANCE Mirror METERS FEET 8.53 8.23 7.92 7.62 Patient 7.32 6"x 6" 7.01 Mirror 6.71 6.40 Project-O-Chart 6.10 8'.0" 5.79 5.49 12'.0" 5.18 4.88 FIGURE 5 4.57 4.27 3.96...
-
Page 9: Slide Selection
BULB LIFE 2. Unplug the power cord from the wall and the instrument. The LongLife P-O-C uses the 11143 Halogen Bulb 3. Remove the rear cover as described in the (20) to produce a superb combination of brightness section on Bulb Replacement (see page 8). -
Page 10: Bulb Replacement
DO NOT REMOVE LENSES FROM THE OBJEC- TIVE BARRELS. require special care during cleaning. Newer slides are typically a metallic deposition on glass and can NOTE: Use only Reichert speciied Hallogen Bulbs. be cleaned more easily. 1. Turn the Instrument “OFF” and unplug the power IMPORTANT: IF YOU ARE NOT SURE WHAT cord from the wall and the instrument. -
Page 11: Letter Sizing Chart (Feet)
LETTER SIZING CHART REFRACTING DISTANCE FEET 12084-101 Rev. D Page 11... -
Page 12: Letter Sizing Chart (Meters)
LETTER SIZING CHART REFRACTING DISTANCE METERS 9.00 9.00 8.75 8.75 8.50 8.50 8.25 8.25 8.00 8.00 7.75 7.75 7.50 7.50 7.25 7.25 7.00 7.00 6.75 6.75 6.50 6.50 6.25 6.25 6.00 6.00 5.75 5.75 5.50 5.50 5.25 5.25 5.00 5.00 4.75 4.75 4.50... -
Page 13: General Specifications
General Speciications Instrument Data: Height: 11.75 in (29.8 cm) (with table mount) 15.50 in (39.4 cm) Width: 4.50 in (11.4 cm) (with table mount) 7.75 in (19.7 cm) Depth: 12.25 in (31.1 cm) (with table mount) 15.75 in (40.0 cm) Weight, unpacked: 4.37 lbs (2.0 kg) -
Page 14: Classifications And Standards
Classiications and Standards The Reichert LongLife POC is designed and manufactured in the USA according to the following equip- ment and classiications and standards: Technical Standards 93/42/EEC IEC 60601 Equipment Classiication per EN Class I. 60601-1 Refer to Note 1. -
Page 15: Warranty
Reichert instruc- tion manual, nor to a product which has been sold, serviced, installed or repaired other than by a Reichert factory, Technical Service Center, or authorized Reichert Dealer.
