Technical Specifications

Projection Distance
Refraction Distance
Number Of Test Charts
Masks
Tilt Range Of Projector
Automatic Switch-Off
Power Requirements
Line Voltage
Line Frequency
Line Fuse On 110V
Line Fuse On 230V
Projection Lamp
Grounding Wire
Protection Class
Degree Of Protection
Power Consumption
Dimensions (Head Only)
Height
Width
Depth
Color
Weight

Symbol Information

The following symbols appear on the AP250:
CAUTION - An instruction that draws attention to the risk of damage to the product.
Consult accompanying documents.
Protective Earth (Ground)
WARNING - Risk of electric shock. Consult accompanying documents.
WARNING - An instruction that draws attention to the risk of injury or death.
Consult accompanying documents.
Alternating Current Power
Waste of Electrical and Electronic Equipment
Date of Manufacture
14
10 Ft (3 M) To 26.5 Ft (8 M)
7.4 Ft (2.3 M) To 30 Ft (9.2 M)
33 Standard Test Charts
- Red/Green, Polarization, Single Horizontal Lines,
- Single Vertical, Single Letters And Single Numbers.
± 15°
After 10 Min. Without Operation.
110 V; 230 V; Margin ± 10%
50 To 60 Hz
500 Ma, Slow Blow/250 V
250 Ma, Slow Blow/250 V
12V/20W Halogen Bulb
Instrument To Be Connected Only To Proper
Outlets With Correct Ground Wire.
1
IP 21
40 VA
7" (17.78 Cm)
8" (20.32)
13" (33.02)
White With Grey Accents
12 Lbs (5.4 Kg)
13800-101-Rev. E
