Inline CIA101 Operation Manual

Computer interface with internal power supply
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CIA1 01 COMPUTER INTERFACE
WITH INTERNAL POWER SUPPLY
CIA 1 0 1
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CIA101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Inline CIA101

Summary of Contents for Inline CIA101

  • Page 1 CIA1 01 COMPUTER INTERFACE WITH INTERNAL POWER SUPPLY CIA 1 0 1 OPERATION MANUAL...

  • Page 2: Fcc Compliance

    Para prevenir un incendio, reemplace solo con el mismo tipo de fusible. CE COMPLIANCE All products exported to Europe by Inline, Inc. after January 1, 1997 have been tested and found to comply with EU Council Directive 89/336/EEC. These devices conform to the following...

  • Page 3: Product Overview

    Product Overview DESCRIPTION The CIA101 is a high-performance computer interface for analog video and stereo audio signals. The unit is compatible with a variety of analog signals including VGA, SVGA, XGA, SXGA, UXGA, MAC, SUN, SGI and other high-resolution workstations. The CIA101’s compact design allows users to place it in a variety of locations or permanently mount it to virtually any flat surface (using the optional L mounting brackets).
  • Page 4 RGsB input signals. OUTPUT The output signal of the CIA101 is analog RGB video with TTL sync on 3, 4 or 5 female BNC connectors. The output format can be set to RGBHV, RGBS or RGsB using dipswitches. This output signal is compatible with high-resolution data grade monitors and data / graphics projectors.

  • Page 5: Installation

    1.) Place / install the CIA101 at the desired location. The unit may be secured to a flat surface using the IN9250 L Mounting Brackets (optional), or installed in a standard 19” equipment rack. Two interfaces can be mounted side-by-side in a 1U rack space (using the optional IN9080 rack shelf).

  • Page 6: Adapter / Extension Cables For Input And Local Monitor Output

    RCA connectors, use the IN9107 audio adapter cable [(1) 3.5mm stereo mini male to (2) RCA male]. 8.) Connect the local computer monitor (if applicable) to the local monitor output port of the CIA101. Monitors with 15-pin VGA connectors will attach directly to the interface. For other types of monitors, refer to the table below.
  • Page 8 CIA101 FRONT PANEL CONNECTORS AND CONTROLS Horizontal Monitor Position Emulation with Control LED Indicator Local Monitor Output Power Indicator Stereo Audio Video Input Input CIA101 REAR PANEL CONNECTORS AND CONTROLS Audio Output Connector Switches ( Balanced or Unbalanced ) Sharpness...

  • Page 9: Horizontal Position Control

    If the horizontal position adjustment is set to an extreme position on either the display device or the CIA101, the output image may appear dark and / or the colors may be displayed improperly. To position the video image and achieve optimum picture quality: 1.

  • Page 10: Dip Switch Settings

    * Factory Default Setting MONITOR EMULATION The factory default setting for the CIA101 is Monitor Emulation Enabled. If the application requires a local monitor, make sure that the front panel Monitor Emulation LED is OFF (press the MONITOR EMULATION Button to toggle between enabled / disabled). If no local monitor is necessary, make sure the Monitor Emulation LED is ON.

  • Page 11: Specifications

    Input and Local Monitor Adapter and Extension Cables: VGA: IN8000 Series 15-pin HD male to 15-pin HD female, various lengths from 3’ to 100’ For Other Computers: See table on page 4 ©2001 - INLINE, Inc. CIA101 Operation Manual - V1.3 01/03/01...

  • Page 12: Troubleshooting

    All cable grades are available in lengths from 3’ to 250’ pre-terminated with high quality BNC connectors or as bulk cable. Troubleshooting Problem: The display device connected to the CIA101 output has a bad / scrambled image. Œ Solution 1: Verify that the correct input cable is being used (see table on page 4).
  • Page 13 Solution 2: Make sure the A/C source is live. Œ Solution 3: The CIA101 contains a 0.125A / 250V time delay fuse. To change the fuse, remove the power cable, then slide out the fuse holder (located on the rear panel between the power switch and the IEC cable receptacle) using the IN9339 adjustment tool.

  • Page 14: Warranty

    If equipment fails because of such defects and INLINE is notified within two (2) years from the date of shipment, INLINE will, at its option, repair or replace the equipment at its plant, provided that the equipment has not been subjected to mechanical, electrical or other abuse or modifications.

This manual is also suitable for:

Cia100
