- Page 1 IN21 1 2R HIGH RESOLUTION RACK MOUNTABLE INTERFACE WITH 2 INPUTS AND STEREO AUDIO SWITCHING IN 2 1 1 2R OPERATION MANUAL...
- Page 2 Para prevenir un incendio, reemplace solo con el mismo tipo de fusible. CE COMPLIANCE All products exported to Europe by Inline, Inc. after January 1, 1997 have been tested and found to comply with EU Council Directive 89/336/EEC. These devices conform to the following...
-
Page 3: Table Of Contents
Table of Contents Product Overview ....................2 Description ......................2 Product Features ....................2 Compatibility......................4 Input ........................4 Output........................4 Adapter and Extension Cables for Input and Local Monitor Output....5 Installation ......................6 Application Diagram..................7 Internal Control Connection................8 Optimal Settings for LCD / DMD / ILA / D-ILA / Plasma Displays ....8 Front Panel Connectors and Controllers ............9 Horizontal Position Control ................9 Stereo Audio Switching ..................10... -
Page 4: Product Overview
Through the use of removable input cables, the IN2112R can be attached to different computers and will provide a video output signal on five BNC connectors. The output signal may be set to RGBHV (default), RGBS or RGsB formats. - Page 5 - The unit can be set for RGBHV, RGBS or RGsB output sync as required by the data display device and signal distribution system. The IN2112R does not strip sync off the green signal (i.e. RGsB input signals appear at the output as RGsB).
-
Page 6: Compatibility
RGsB input signals. OUTPUT The output signal of the IN2112R is analog RGB video with TTL sync on 3, 4 or 5 female BNC connectors. The output format can be set to RGBHV, RGBS or RGsB using dipswitches. This output signal is compatible with high-resolution data grade monitors and data / graphics projectors. -
Page 7: Adapter And Extension Cables For Input And Local Monitor Output
ADAPTER / EXTENSION CABLES FOR INPUT AND LOCAL MONITOR OUTPUT The IN2112R has 15-pin HD VGA-type connectors for input and local monitor output. The following input and local monitor output cables are available: Computer 3’... -
Page 8: Installation
/ Plasma Display devices, please refer to Page 8. 3. Connect the IN2112R output (5 BNC connectors) to the data display device's RGB input, using three, four or five high-resolution BNC cables or a multi-conductor RGBHV, RGBS or RGB "snake". The IN7000 / IN7100 / IN7200 / IN7300 Series high-resolution cables and the IN8800 Series installation cables are well suited for this purpose. -
Page 9: Application Diagram
10. Connect the local computer monitor (if present) to the local monitor output of the IN2112R. VGA monitors will attach directly to the local monitor output. For other types of monitors, use the appropriate local monitor output adapter cable (see list on page 5). If no local monitor is used, set the monitor emulation dipswitch to emulate a color VGA monitor or a 13/14”... -
Page 10: Internal Control Connection
#2 Set to ON / All other dipswitches set to OFF Signal Format: Red / Green / Blue / Horizontal and Vertical Sync Horizontal Position Control: Disabled H & V Sync Polarity: Mirror Input Polarities IN2112R OPERATION MANUAL - PRELIMINARY 8/23/99 ©1999 - INLINE, INC. -
Page 11: Front Panel Connectors And Controllers
The following procedure is suggested to ensure best results: 1. Adjust the IN2112R horizontal position control so a good quality image is displayed. This control should not be set to an extreme position. -
Page 12: Stereo Audio Switching
STEREO AUDIO SWITCHING The IN2112R provides stereo audio-follow-video switching to accommodate stereo audio signals from a computer audio card or other stereo audio sources. Whenever Input 1 or Input 2 is selected, the corresponding stereo audio signal is routed to the audio output connector on the back of the interface, which is normally connected to a house sound system. -
Page 13: Dipswitch Settings
DIPSWITCH SETTINGS Most installations will not require any changes to the dipswitch settings, and the IN2112R will generally be operated with the factory default settings. The Factory Default settings and specialized dipswitch settings are indicated below. Please note that when the interface is held upright, the dipswitches are numbered from 10 to 1 as shown below. -
Page 14: Audio / Video / Phone / Data / Switch / Computer Connector Modules
IN9373B / IN9373W (2) RCA Barrel (2) RCA Female (2) RCA Female Single (1) 9-Pin D Gender IN9374B / IN9374W (1) 9-pin D Female (1) 9-pin D Female Single Changer – Female IN2112R OPERATION MANUAL - PRELIMINARY 8/23/99 ©1999 - INLINE, INC. - Page 15 (3) Solder Cups Double IN9395DW IN9396DB / (1) 6-pin XLR Switchcraft 6-pin XLR Female (6) Solder Cups Double IN9396DW Note: When ordering the IN2112R, please specify the necessary A/V connector modules. ©1999 - INLINE, INC. IN2112R OPERATION MANUAL - PRELIMINARY 08/31/00...
-
Page 16: Specifications
IN2112R-IEC: (2) IEC female IN2112R-EU: (2) Euro female Regulatory Compliance Safety UL 1950, CAN/CSA-22.2 No. 950 3 FCC class A; CE: EN50022 (1987), EN50081-1 (1991), EN50082-1 (1992 & 1994), EN60950-92 IN2112R OPERATION MANUAL - PRELIMINARY 8/23/99 ©1999 - INLINE, INC. -
Page 17: Rgb Output Cables
Parts Included (1) IN2112R Rack Mountable Interface (1) IN9334 3/32 Allen Wrench for IN2112R Connector Module Set Screws (1) IEC Power Cable (1) Operation Manuel Required Accessories (Ordered Separately) Input and Local Monitor Adapter and Extension Cables: VGA: IN8000 Series 15-pin HD male to 15-pin HD female, various lengths from 3’ to 100’... -
Page 18: Troubleshooting
Solution 4: The RGBS or RGBHV cable may have a bad sync line. Try running the sync through another cable. Solution 5: The IN2112R output sync range may not be compatible with the display device. Check the resolution and refresh rate for both the computer graphics card and the data display device to ensure compatibility. -
Page 19: Warranty
The information in this manual has been carefully checked and is believed to be accurate. However, INLINE, Inc. assumes no responsibility for any inaccuracies that may be contained in this manual. In no event will INLINE, Inc. be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages.
