- Page 1 OPERATION MANUAL Installation Interface Series IN2116 Table Mountable Interface...
- Page 2 Installation and Safety Instructions For Models without a Power Switch: The socket outlet shall be installed near the equipment and shall be accessible. For Models with 110 / 220V Power Selector: Caution: Before applying power to this unit, the voltage selector must be set to the appropriate setting to match local A/C line voltage.
- Page 3 Installations und Sicherheitshinweise Für Geräte ohne Netzschalter: Die Netzsteckdose soll in de Nähe des Gerätes installiert und frei zugänglich sein. Für Geräte mit 110 / 220V Spannungswähler: Achtung: Bevor Sie dem Gerät Spann ung zuführen, muß der Spannungswähler entsprechend der Spannung des lokalen Wechselspannungsnetzes eingestellt werden.
- Page 4 CE COMPLIANCE All products exported to Europe by Inline, Inc. after January 1, 1997 have been tested and found to comply with EU Council Directive 89/336/EEC. These devices conform to the following standards: EN50081-1 (1991), EN55022 (1987) EN50082-1 (1992 and 1994), EN60950-92...
-
Page 5: Table Of Contents
Adapter and Extension Cables for Input and Local Monitor Output....5 Installation ......................6 IN2116 Application Diagram ................7 IN2116 Front Panel Connectors and Controls..........8 Horizontal Position Control ................8 Dipswitch Settings ....................9 Optimal Settings for LCD / DMD / ILA / D-ILA / Plasma Displays ....9 IN9370 Audio Buffer Module ................10... -
Page 6: Product Overview
Through the use of removable input cables, the IN2116 can be attached to different computers and will provide a video output signal on five BNC connectors. The output signal may be set to RGBHV (default), RGBS or RGsB formats. - Page 7 RJ45 jack (for quick access to the computer network) and the 3.5mm stereo mini or dual RCA jacks (to connect the computer’s sound card output to the room’s sound system). The IN2116 can hold double size connector plates to accommodate large connectors such as XLR. The IN2116 simplifies the design and installation process since a single unit fills the function of both video interface and A/V connector plate.
-
Page 8: Compatibility
RGsB input signals. OUTPUT The output signal of the IN2116 is analog RGB video with TTL sync on 3, 4 or 5 female BNC connectors. The output format can be set to RGBHV, RGBS or RGsB using dipswitches. This output signal is compatible with high-resolution data grade monitors and data / graphics projectors. -
Page 9: Adapter And Extension Cables For Input And Local Monitor Output
ADAPTER / EXTENSION CABLES FOR INPUT AND LOCAL MONITOR OUTPUT The IN2116 has 15-pin HD VGA-type connectors for input and local monitor output. The following input and local monitor output cables are available: Computer 3’ 6’ 12’ 25’ VGA: 15-Pin HD... -
Page 10: Installation
4. Connect the accessory cables as required by your installation. 5. Connect the IN9230 Power Cord (included) to the IN2116. The LED on the front of the unit should light-up to indicate it is on. -
Page 11: In2116 Application Diagram
MAXIMUM POWER: 800W High Resolution Video Interface LOCAL INPUT MONITOR HORIZONTAL POSITION FRONT VIEW IN8000 series IN9106 CAT5 VGA Extension Cable Audio Cable LAN Cable IN8700 IN7200-1 Audio Cable Video Cable WCTÃW8S ©1999 - INLINE, INC. IN2116 OPERATION MANUAL - PRELIMINARY 12/03/99... -
Page 12: In2116 Front Panel Connectors And Controls
The following procedure is suggested to ensure best results: 1. Adjust the IN2116 horizontal position control so a good quality image is displayed. This control should not be set to an extreme position. -
Page 13: Dipswitch Settings
DIPSWITCH SETTINGS Most installations will not require any changes to the dipswitch settings, and the IN2116 will generally be operated with the factory default settings. The factory default and specialized dipswitch settings are indicated below. Factory Default Settings: Dipswitches ON: 2 &... -
Page 14: In9370 Audio Buffer Module
IN9370 AUDIO BUFFER MODULE The IN2116 can be ordered with a IN9370 audio buffer module. This factory installed optional module takes an unbalanced stereo audio input, buffers the signal and outputs it as balanced stereo audio. This is desirable for systems where the IN2116 audio signal will be connected to equipment with balanced audio inputs, and is helpful in preserving signal integrity and minimizing outside signal interference (which often occurs while sending the audio signal over lengthy cable runs). -
Page 15: Audio / Video / Phone / Data / Switch / Computer Connector Modules
AUDIO / VIDEO / PHONE / DATA / SWITCH / COMPUTER CONNECTOR MODULES Modular A/V Connector Plates & Accessories for: IN2111 Series / IN2112 Series / IN2114 Series / IN2116 / IN3260 / IN9166 / IN9167 / IN9168 Connector Module... - Page 16 (3) Solder Cups Double IN9395DW IN9396DB / (1) 6-pin XLR Switchcraft 6-pin XLR Female (6) Solder Cups Double IN9396DW Note: When ordering the IN2116, please specify the necessary A/V connector modules. IN2116 OPERATION MANUAL - PRELIMINARY 12/03/99 ©1999 - INLINE, INC.
-
Page 17: Specifications
British, European and Australian Models Regulatory Compliance UL 1950. 3 Ed.; CE: EN50081-1 Safety CAN/CSA-22.2 No. 950 3 FCC class A; CE: EN50022 (1987), EN50081-1 (1991), EN50082-1 (1992 & 1994), EN60950-92 ©1999 - INLINE, INC. IN2116 OPERATION MANUAL - PRELIMINARY 12/03/99... -
Page 18: Rgb Output Cables
Parts Included (1) IN2116 Table Mountable Installation Interface (1) IN9334 3/32 Allen Wrench for IN2116 Connector Module Set Screws (1) IEC Power Cable (1) Operation Manuel Required Accessories (Ordered Separately) Input and Local Monitor Adapter and Extension Cables: VGA: IN8000 Series 15-pin HD male to 15-pin HD female, various lengths from 3’ to 100’... -
Page 19: Troubleshooting
Solution 4: The RGBS or RGBHV cable may have a bad sync line. Try running the sync through another cable. Solution 5: The IN2116 output sync range may not be compatible with the display device. Check the resolution and refresh rate for both the computer graphics card and the data display device to ensure compatibility. -
Page 20: Warranty
The information in this manual has been carefully checked and is believed to be accurate. However, INLINE, Inc. assumes no responsibility for any inaccuracies that may be contained in this manual. In no event will INLINE, Inc. be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. - Page 21 12.50“ IN2116 Front View 11.75“ IN2116 Top View Mounting Holes: 0.156“ / 4 mm Diameter (4) #6 Wood Screws Included 12.125“ 0.187“...
