  • Page 3: Product Overview

    CIA100 simplifies interfacing tasks by acting as a universal adapter. Through the use of removable input cables, the CIA100 can be attached to different computers and will provide a video output signal on five BNC connectors. The output signal may be set to RGBHV (default), RGBS or RGsB formats.
  • Page 4 RGsB input signals. OUTPUT The output signal of the CIA100 is analog RGB video with TTL sync on 3, 4 or 5 female BNC connectors. The output format can be set to RGBHV, RGBS or RGsB using dipswitches. This output signal is compatible with high-resolution data grade monitors and data / graphics projectors.
  • Page 5: Installation

    1.) Place / install the CIA100 at the desired location, making sure that the unit is seated on a flat surface. The unit can be mounted to virtually any flat surface using the optional IN9250 L Mounting Brackets that attach to the sides of the unit.
  • Page 6: Adapter / Extension Cables For Input And Local Monitor Output

    Vertrieb von CAMBOARD Electronics 7.) Apply power to the CIA100 using the IN9205 9 VDC; 1.0A power supply (included). The power LED on the front of the unit will illuminate. 8.) Complete the installation by turning the computer and computer monitor on. If required, adjust the horizontal position control to center the image on the data display device (see the Horizontal Position Control Section on page 7 for more details).
  • Page 7 im Vertrieb von CAMBOARD Electronics www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 8: Power Connector

    Vertrieb von CAMBOARD Electronics CIA100 FRONT PANEL CONNECTORS AND CONTROLS Horizontal Monitor Position Emulation with Control LED Indicator Video Input Local Monitor Output Power Indicator CIA100 REAR PANEL CONNECTORS AND CONTROLS Switches Power Connector Video Output Connectors CIA100 Operation Manual - V1.3 01/03/01 ©2001 - INLINE, Inc.
  • Page 9: Horizontal Position Control

    If the horizontal position adjustment is set to an extreme position on either the display device or the CIA100, the output image may appear dark and / or the colors may be displayed improperly. To position the video image and achieve optimum picture quality: 1.
  • Page 10: Monitor Emulation

    Output Sync Format - All CIA100 Series Interfaces feature advanced sync processing circuitry that offers superb compatibility with a wide range of display devices. The CIA100 has been designed (and extensively tested) to provide excellent operation when set for RGBHV, RGBS and RGsB output signal formats.
  • Page 11: Specifications

    IN9210: Rack Mountable Power Supply (powers up to ten 9VDC / 12VDC devices) Mounting Hardware: IN9250: L Mounting Brackets - For Mounting CIA100 to Flat Surface IN9251: Flush Mount Brackets - For Mounting CIA100 Through Hole in Table Top ©2001 - INLINE, Inc. CIA100 Operation Manual - V1.3 01/03/01 www.camboard.de...
  • Page 12: Troubleshooting

    All cable grades are available in lengths from 3’ to 250’ pre-terminated with high quality BNC connectors or as bulk cable. Troubleshooting Problem: The display device connected to the CIA100 output has a bad / scrambled image. Œ Solution 1: Verify that the correct input cable is being used (see table on page 4).
  • Page 13 This problem often occurs when a 31.5 KHz VGA signal is sent into an RGB monitor that is only compatible with signals at 15.75 KHz. If problems persist, call INLINE Technical Services at (714) 921-4100 for further assistance. ©2001 - INLINE, Inc.
