Inline IN2013HR Operation Manual

High resolution video interface for 13w3 workstations
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IN2013HR HIGH RESOLUTION VIDEO INTERFACE
FOR 13W3 WORKSTATIONS
IN20 1 3HR
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IN2013HR and is the answer not in the manual?

Questions and answers

Related Manuals for Inline IN2013HR

Summary of Contents for Inline IN2013HR

  • Page 1 IN2013HR HIGH RESOLUTION VIDEO INTERFACE FOR 13W3 WORKSTATIONS IN20 1 3HR OPERATION MANUAL...

  • Page 2: Fcc Compliance

    Para prevenir un incendio, reemplace solo con el mismo tipo de fusible. CE COMPLIANCE All products exported to Europe by Inline, Inc. after January 1, 1997 have been tested and found to comply with EU Council Directive 89/336/EEC. These devices conform to the following...

  • Page 3: Product Overview

    RGsB, RGBS, RGBHV or Composite Monochrome. Dual Outputs - the IN2013HR can drive two display devices in addition to the local monitor. Flexible Monitor Emulation - The interface automatically sets itself to the appropriate resolution / refresh rate, or can be used without a local display device (dipswitches are provided to emulate virtually any monitor).
  • Page 4 Convenient Controls - The IN2013HR offers intuitive front panel controls for the most important signal adjustments. Gain Control - adjusts the voltage level of the RGB components simultaneously (ensuring that gray scale is maintained), and may be used to compensate for signal loss due to long cable runs.

  • Page 5: Installation

    3. Check the Input Signal Configuration Settings - (SWITCH 1 - Dipswitches 8 / 9 / 10) which are on the bottom of the IN2013HR. The factory default settings for dipswitches 8, 9 and 10 will work with Sun workstations and most SGI computers. For other computers,...
  • Page 6 6. Apply Power - to the IN2013HR using the IN9230 IEC power cable (included). 7. Turn On - the computer, the IN2013HR, the local monitor (if applicable) and the display device. If necessary, adjust the gain, sharpness and / or horizontal position control as detailed on pages 6 and 7.

  • Page 8: Front Panel Controls

    If the horizontal position adjustment is set to an extreme position on either the display device or the IN2013HR, the output image may appear dark and / or the colors may be displayed improperly. To position the video image and achieve optimum picture quality: 1.

  • Page 9: Dip Switch Settings

    (dipswitches 8-10). The SWITCH 2 panel determines the monitor emulation settings. SWITCH 1 For most installations, the IN2013HR will be operated in the factory default mode and will not require any changes to the dipswitch settings. The factory default settings are: SWITCH 1 Dipswitches ON: 1, 3, 5, 6, 7 &...
  • Page 10 7 = 0 INPUT SIGNAL FORMAT SELECTION The IN2013HR is set at the factory for automatic operation with SUN and most SGI computers (*dipswitches 8 / 9 / 10 off). For other computers or signal formats, carefully set dipswitches 8, 9 and...
  • Page 11 SWITCH 2 (MONITOR EMULATION) The IN2013HR includes a bank of 10 dipswitches (SWITCH 2) on the bottom side of the interface for monitor emulation. Setting the dipswitches to the appropriate positions allows the unit to emulate the appropriate sense signals, thus setting the video card to the desired frequency, refresh rate and resolution, even without a local monitor.

  • Page 12: Specifications

    Internal Switch Mode: 90 - 260 VAC; 0.29A; 47 - 63 Hz Power Consumption 14.5 Watts Regulatory Compliance UL 1950, CAN/CSA-22.2 No. 950 3 Safety & EMI FCC class A; CE: EN50022 (1987), EN50081-1 (1991), EN50082-1 (1992 & 1994), EN60950-92 IN2013HR Operation Manual - V1.0 12/05/00 ©2000 - INLINE, Inc.

  • Page 13: Troubleshooting

    Solution 2: Make sure the A/C source is live. ΠSolution 3: The IN2013HR contains a 0.5A / 250V time delay fuse. To change the fuse, first remove power from the unit and then slide out the fuse holder (located on the rear panel between the power switch and the IEC cable receptacle) using the IN9339 Alignment Tool (included).
  • Page 14 Problem: The output image is very bright and appears “overdriven” with poor contrast. Œ Solution 1: Verify the gain setting on the IN2013HR. If it is set to a very high level, reduce the gain control setting as required. Œ...

  • Page 15: Warranty

    If equipment fails because of such defects and INLINE is notified within two (2) years from the date of shipment, INLINE will, at its option, repair or replace the equipment at its plant, provided that the equipment has not been subjected to mechanical, electrical or other abuse or modifications.
