G Step 1
1. Check the model of the indoor unit to be controlled from the wireless remote controller.
2. Refer to the table of model numbers and find the model number that corresponds to the model of indoor unit to be controlled. Make the settings
according to the operation procedures.
Indoor unit model name (Only the prototypes are shown.)
Cooling/
Model
heating Type
No.
PLFY-AM model
PLFY-JM model
PMFY-BM model
001
PCFY-GM model
Factory
PKFY-AM model
setting
PKFY-GM model
002
PLFY-LMD (22~112) model
009
PLFY-LMD (140) model
Cooling/
Heating Type
015
PMFY-EM model
(Cool/Dry/Auto/
017
PDFY-M (22~80) model
Fan/Heat)
PCFY-HM model
PDFY-M (90~140 ) model
PEFY-AM model
019
PEFY-M (45~160) model
PFFY-LEM model
PFFY-LRM model
020
PEFY-M (224~280) model
PFFY-DM model
023
PSFY-GM model
Note 1: If the settings that are related to the remote controller operation are changed on the function selection menu, make the setting for the model
number by referring to the table of model numbers.
(i.e., Changes to the vane adjustment setting (Function selection mode 11) or Swing setting (Function selection mode 23))
Note 2: Some indoor units with the same model name may have different functions, depending on the capacity type and production year. Refer to the
applicable technical document to confirm the functions that are available to a given unit, and make an appropriate setting for the model number
according to the table of model numbers.
Note 3: To set the model number for the indoor unit that is not listed in the table above, check the functions that are available to it in the applicable
technical document, and make an appropriate setting for the model number according to the table of model numbers.
MODEL SELECT
Setting No.
Model No.
TEMP
ON/OFF
TEMP buttons
ON/OFF
button
FAN
AUTO STOP
MODE
VANE
AUTO START
CHECK
LOUVER
h
TEST RUN
min
SET
RESET
CLOCK
SET button
AAA
AAA
G Step 2
1. Refer to the applicable technical document to confirm the functions that are available to a given unit, and make an appropriate setting by finding the
model number that corresponds to the pattern of those available functions.
2. Setting procedures are the same for those listed under Step 1.
14 speeds
1.Fan speed
23 speeds
32 speeds
4Fixed speed
2.Louver swing
1Disabled
(horizontal air
2Enabled
direction control)
1Adjustable vane/Auto swing enabled
3.Vane
(vertical air
2Adjustable vane/Auto swing disabled
direction control)
3Fixed
4Undefined (Fixed)
1Cool/Dry/Auto/Fan/Heat
4.Operation
mode
2Cool/Dry/Fan
3Cool/Dry/Auto/Heat
4Cool/Dry/Auto/Fan/Combustion Heat/Heat
5Cool/Fan
6Cool/Auto/Fan/Heat
7Cool/Fan/Heat
8Cool/Dry/Fan/Heat
Table of Model Numbers
CITY MULTI system
[Setting Procedures]
1. Push the SET button with a pointed but not sharp
object.
Make sure that the remote controller display in-
dicates that the unit is stopped.
2. Use the TEMP
ber.
Functions that correspond to each model num-
ber will appear on the display.
3. Press the set button again with a pointed but not
sharp object.
• Press the ON/OFF
ber is correctly set.
001 002 003 004 005 006 007 008 009 010 011 012 013 014 015 016 017 018 019 020 021 022 023 024 025 026 027 028 029 030 031 032 033 034 035 036 037 038 039 040 041 042 043
Model number
Indoor unit model name (Only the prototypes are shown.)
Cooling/
Model
heating Type
No.
PLFY-AM model
PLFY-JM model
PMFY-BM model
033
PCFY-GM model
PKFY-AM model
PKFY-GM model
034
PLFY-LMD (22~112) model
041
PLFY-LMD (140) model
Cooling only
047
PMFY-EM model
type
049
PDFY-M (22~80) model
(Cool/Dry/Fan)
PCFY-HM model
PDFY-M (90~140) model
PEFY-AM model
051
PEFY-M (45~160) model
PFFY-LEM model
PFFY-LRM model
052
PEFY-M (224~280) model
PFFY-DM model
055
PSFY-GM model
buttons to set the model num-
button to turn on the remote controller display, and confirm that the model num-
Table of Model Numbers
CITY MULTI system
MODEL SELECT
will blink, and model number "001" will
be lit. (It is set to "001" at factory shipment.)
• If an error is made, press the ON/OFF
to cancel, and enter the model number again.
MODEL SELECT
and the model number that was entered
will stay lit for three seconds and then go off.
button
3
