  • Page 1 guide...
  • Page 2 Visit the GARMIN website for current updates and supplemental information concerning the use and operation of this and other GARMIN products.

  • Page 3: About This Manual

    About This Manual Thank you for choosing the GARMIN eMap. To get the most from your new eMap, take time to read through this owner’s manual in order to understand all of the operating features. This manual is organized into four sections.

  • Page 4: Fcc Compliance Statement

    The eMap does not contain any user-serviceable parts. Repairs should only be made by an authorized GARMIN service center. Unauthorized repairs or modifications could result in permanent damage to the equipment, and can void your warranty and your authority to operate this device under Part 15 regulations.
  • Page 5 Do not mount the eMap over air bag panels or in the field of air bag deployment. AIr bags expand with a rapid force that can propel objects in their path toward !"#$"%#&"'(%...

  • Page 6: Table Of Contents

    Warnings and Precautions......ii-iii Using the Find Menu......21-25 Using Goto.........26 The Main Menu...........27 The Trip Computer........27 Section Two - Getting Started Tracks Page........28 eMap Key Function........1 Route Page........29 BatteryInstallation........2 The GPS Info Page........30 Start-Up.............2 Sun and Moon Page........31 Determining Your Location......3 MapSource Info........31...

  • Page 7: Emap Key Function

    SECTION 2 eMap !"#$%"&' Key Function ()*+,"#$""& /012'&3 2);CD+4$3  Press and release to turn the eMap On.  Press and hold to turn the eMap Off. /-EFGHIJBK )AB+4$3 E)$BD-LB Displays increasingly larger map areas with less  Press and release to detail.

  • Page 8: Batteryinstallation

    Start Up Start Up The eMap To Start Up the eMap, take the unit outside and find an open area where the built-in antenna has a clear view of the sky. Hold the receiver at a comfortable height with the front of the eMap pointing up.

  • Page 9: Determining Your Location

    Getting Started Determining Your Each time you turn on the eMap it must determine its Location location. The first time you use your eMap, this may take from five to fifteen minutes. After first use, the eMap should determine your location in less than one minute.

  • Page 10: Data Fields

    A Goto Track - A previous path of travel that has been stored (logged) in the eMap. A Track allows you to repeat a path or to return to your starting point on the same path using the GARMIN TracBack ®...
  • Page 11 In many instances the map will display an ‘Accuracy Position Icon Circle’ surrounding the ‘Position Icon’. The eMap uses both map resolution and GPS accuracy in defining your location to a point within the circle. The smaller the circle, the more accurate your location.

  • Page 12: The Map Page Options Menu

    Map Page Options The Map Page Options Map Page options allow a variety of operating and customizing features for the eMap. Pressing the MENU key from the Map Page will display the Map Page Options Menu. Not all of the Map Page options are available at the same time.

  • Page 13: The Main Menu

    Getting Started The Main Menu The Main Menu The Main Menu provides access to additional eMap feature pages. The pages listed below provide either enhancements to eMap operation or display data about operating information. Press the MENU key twice to display the Main Menu.

  • Page 14: The Find Menu

    Getting Started The Find Menu The Find Menu The Find Menu allows you to find stored locations (waypoints) and map items (cities, exits, etc.). They can be found by name or those nearest to your Current Location (Position Icon) or to the Map Pointer (Panning Arrow). Press the FIND key to access the Find Menu.

  • Page 15: Contrast Settings

    Refer to ‘Time Settings’ on page 32. Beeper Tones What Beeper Tones Mean The eMap Beeper produces three types of signals. Single Beep - Indicates that a key has been pressed. Two Beeps - Indicate that a message has been displayed with information about unit operation.

  • Page 16: Map Data Card Installation

    Map Data Transfer Map Data After you have installed a data card in the eMap, it must be loaded with map data from a MapSource CD-ROM. In order to transfer map data you will need to install MapSource on your PC and connect the eMap PC Interface Cable to your PC and the eMap unit.

  • Page 17: Option Menus

    SECTION 3 Reference How To Use Option Menus Option Menus Option Menus are lists of options that are specific for each page. To select and use an option: 1. With any page displayed, press the MENU key to display the option menu for that page. 2.

  • Page 18: Entering Data

    Reference Entering Data How To Enter Data Some pages contain Data Fields that allow you to define the Data entered using the information that will be placed in that field. Data can be entered ROCKER keypad. in two ways; by entering each letter or number, or by selecting from lists of pre-defined information.

  • Page 19: Zooming In And Out

    With certain types of MapSource data, such as MetroGuide data, the eMap may match your location to roads on the map. In these instances, the ‘Accuracy Circle’ (discussed on page 5) will not be shown.
  • Page 20 Reference Using the Panning Arrow The Map Page The Map Page pan function allows you to display an arrow to point at and identify items on the map, and to move the map in order to view areas beyond the current viewing area on the display.

  • Page 21: Map Page Options

    Reference More About Map Page Options Map Page Here is a more detailed description about the Map Page Options options discussed on page 6 with instructions for activation. Use Indoors The ‘Use Indoors’ option stops satellite reception, conserves power usage, and speeds Map Page drawing. The ‘Use Outdoors’...

  • Page 22: Stop Navigation

    ‘Show Next Street’ option The next street name will be displayed only if the eMap is “matching” your position to roads on the map and there is a nearby street. The next interstate exit will be displayed only if you are traveling on an interstate highway.

  • Page 23: Map

    Reference Map Page Setup Map Options The Setup Map Option displays the Map Setup Pages. Map Setup pages determine how the map is displayed, allowing you Map Options to custom tailor the map display. Common Settings Text - Specifies the text size for a displayed map item. Selecting ‘None’...

  • Page 24: Waypoints

    Waypoints Waypoints A waypoint is a location you have identified and stored in the eMap. The eMap can store 500 waypoints in memory. Waypoints can be used to build Routes and as destinations to ‘Goto’. Marking your current location as a waypoint: 1.

  • Page 25: Creating A Waypoint

    Reference To create a waypoint using the panning Creating a arrow when a map item is not highlighted: Waypoint 1. Press and release the ENTER key with the panning arrow positioned where you want to mark the waypoint (off of roads, streets or other map items). 2.

  • Page 26: Editing A Waypoint

    Reference Editing a Waypoint Editing a A waypoint can be edited to change the map symbol, name, Waypoint coordinates, or elevation. It can also be deleted. To edit a waypoint: 1. Use the Find feature as described on page 21 or use the panning arrow to highlight a waypoint on the map and press ENTER to display the Waypoint Page.
  • Page 27 Using the You can locate Waypoints, Cities, and Interstate Exits Find Menu included in the eMap basemap. You can also locate Cities, Exits, Points of Interest, Addresses and Intersections when using MapSource data. Cities and Points of Interest are also available in other selected MapSource maps.

  • Page 28: Using The Find Menu

    Reference Finding a Waypoint Using the Waypoints that you have created and stored in the eMap Find Menu can be found by selecting the ‘Waypoint’ option of the Find Menu. You can find a waypoint from a list of waypoints ‘By Name’...

  • Page 29: Finding An Exit

    Reference Finding an Exit Using the You can use the Find Exit option to locate a nearby exit on Find Menu an interstate highway. Exits are listed only by ‘Nearest’. To find an Exit: 1. Press the FIND key to display the Find Menu. 2.

  • Page 30: Finding A Point Of Interest

    Reference Finding a Point of Interest Using the You must be using MapSource MetroGuide which Find Menu provides this type of map data, otherwise this option will appear gray and will not be available. To locate a point of interest: 1.
  • Page 31 Reference Using the Finding an Address or an Intersection Find Menu You must be using MapSource MetroGuide which provides this type of map data, otherwise these options will appear gray and will not be available. To locate an address: 1. Press the FIND key to display the Find Feature Menu.

  • Page 32: Using Goto

    Using Goto To Goto to a map item or Find Menu item You can use the eMap to guide you to a map or Find Menu item using the Goto feature. A Goto is a straight-line from your current location to one you’ve selected.

  • Page 33: The Main Menu

    Reference Using the Main Menu The Main Menu provides access to additional eMap Main Menu features that are explained on following pages. For an introduction to the Main Menu, refer to page 7. To display the Main Menu, press the MENU key twice.

  • Page 34: Tracks Page

    Reference Tracks Page Saving and Using a Track The eMap automatically records a history of your locations in the ‘Track Log’, creating an electronic ‘breadcrumb’ trail of the path you have traveled. You may save all or part of the track log to create a ‘Track’.

  • Page 35: Route Page

    Route navigation allows you to create a sequence of intermediate waypoints which lead you to your final destination. The eMap will store fifty routes, each with up to fifty waypoints. A Route can be created and modified from the Route Page or complex routes can be created on a PC and transferred into the eMap.

  • Page 36: The Gps Info Page

    Solid bars indicate Elevation and Location - You can set a new elevation acquired satellites and are and new location to help the eMap obtain a position fix. identified by the highlighted These two options will not be available if your location numbers in the skyview.

  • Page 37: Sun And Moon Page

    Current Time’ from the Sun and Moon Page option menu. The Rise and Set times are displayed using the time zone that the eMap is set to, not the time zone of the location selected. Sun & Moon Option Menu...

  • Page 38: System Setup Options

    ‘Battery Saver’ with a less frequent satellite signal updating process to save on battery power, and ‘GPS Off’ which allows you to operate the eMap with GPS receiver turned Off to save even more on battery power. ‘General’ Settings Page The ‘Use Indoors’...

  • Page 39: Advanced Settings

    Choose the ‘User’ datum for custom designed grids. Map Datum Options Menu North Reference - Allows control of what the eMap considers ‘North’. True - Uses True North. Magnetic - Uses Magnetic North, which is continually updated based on your current location.

  • Page 40: Interface Settings

    The ‘Interface’ Settings Page allows you to choose from seven different input/output serial data formats, or none at all. This feature is used when connecting your eMap unit to external NMEA devices, DGPS beacon receiver, a personal computer, etc. It is necessary to have a working knowledge of these applica- tions.

  • Page 41: Appendix A: Accessories

    Vehicle Suction Mount PC Interface Cable w/Vehicle Power Adapter - Allows transfer of map data from a PC to an eMap data cartridge and provides unit operation from an automobile cigarette lighter. (3-VDC output) Data Cable - Wiring harness.

  • Page 42: Appendix B: Specifications

    Selective Availability Program. 2. With optional GARMIN GBR 21 Beacon Receiver input. 3. The temperature rating for the eMap may exceed the usable range of some batteries. Alkaline batteries can rupture at high temperatures. Alkaline batteries lose a significant amount of their capacity as temperature decreases. If using the eMap in below freezing temperatures, use lithium batteries for longer battery life.

  • Page 43: Appendix C: Messages

    None Found - There is no such address, intersection, point of interest, or city in the map information database. Check spelling or number entry and try again. RAM Failed - The eMap has detected a failure in its internal memory. If the message persists, service is required.

  • Page 44: Appendix D: Maintenance

    Customer Service at then turns OFF. exhausted. 800-800-1020. Can’t highlight MapSource MetroGuide Install a map data card Find Features. map data required. and transfer MetroGuide. The eMap is programmed to provide “pop-up” messages concerning operational characteristics and conditions. Refer to Appendix C.

  • Page 45: Appendix E: Wiring/Interfaces

    /or a second GPS receiver. The NMEA 0183 version 2.3 interface format is supported by the eMap and enables the unit to drive up to three NMEA devices. NMEA 0183 Version 2.3 Approved Sentences: GPGGA, GPGLL, GPGSA, GPGSV, GPRMB, GPRMC,...

  • Page 46: Appendix F: Utc Time Offset Chart

    Appendix F UTC Time This chart is provided to help you determine the time Offset Chart offset settings for your current location if it is not in one of the time zones listed on the Time Setup Page. To change the UTC Offset, if necessary, press the MENU key twice to access the Main Menu.

  • Page 47: Appendix G: Mapsource Data

    MapSource MapSource CD-ROM data transferred to the map data Data card can dramatically increase the mapping capability of the eMap in both the amount of map detail and available maps. ® MetroGuide maps contain detailed information and are MapSource PC system...

  • Page 48: Appendix H: Limited Warranty

    GARMIN warranty service station. A copy of the original sales receipt is required as the proof of purchase for warranty repairs. GARMIN retains the exclusive right to repair or replace the unit or software or offer a full refund of the purchase price at its sole discretion.

  • Page 49: Appendix I: Index

    Appendix I Index Addresses, Finding.........25 Goto Function........4, 26 Altitude Entry........30 GPS Info Page........30 Antenna..........1, 2 Grids(Map)..........33 Arrow, Panning........5, 14 AutoZoom............17 Averaging Location........20 Highlighting........11-12 Accessories..........35 In Key..........1, 13 Backlighting/Contrast Key......1 Interface Formats......34, 39 Backlighting........1, 9, 32 Intersections, Finding......25 Battery Installation/Replacement....2 Battery Level Indicator......27 Battery Type...........2 Key Usage..........1 Bearing (Direction)........4...

  • Page 50: Appendix I: Index

    Appendix I Index Starting Up.........2-3 Stop Navigation........16 Submenus..........12-13 Sun and Moon Page (Celestial)....31 Navigation on the Map Page......4 System INfoo Page........31 Nearest Cities List........22 Nearest Exits List........23 Nearest Points of Interest......24 Time format...........32 Nearest Waypoints List......21 Time Settings........32, 40 North Reference.........33 Time Setup........32, 40 North Up..........17, 30 Track..........4, 28...

  • Page 51: Serial Number

    Product Registration Help us to better support you by completing our on-line registration today! Have the serial number of your eMap handy and connect to our website (www.garmin.com). Look for the Product Registration link on the Home Page. Why should you register your eMap unit? •...
  • Page 52 © 1999-2001 GARMIN Corporation GARMIN International, Inc. 1200 E 151 Street, Olathe, KS 66062 U.S.A. GARMIN (Europe) Ltd. Unit 5, The Quadrangle, Abbey Park Industrial Estate, Romsey, SO51, 9AQ U.K. GARMIN (Asia) Corporation No. 68, Jangshu 2 Road, Shijr, Taipei County, Taiwan www.garmin.com...
