Carephone 52+
en
Operating Manual

Advertisement

   Related Manuals for Bosch Carephone 52+

   Summary of Contents for Bosch Carephone 52+

  • Page 1

    Carephone 52+ Operating Manual...

  • Page 3: Table Of Contents

    Light signals of the Carephone 52+ 10.2 Sound signals of the Carephone 52+ 10.3 Voice messages of the Carephone 52+ Installation 11.1 Placing the Carephone 52+ 11.2 Connecting the Carephone 52+ Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 4: Table Of Contents

    Resetting the Carephone 52+ to its factory settings Additional Devices 13.1 Detectors 13.2 Microphone/loudspeaker Maintenance Conformity Replacing the Backup Battery Battery Disposal Technical Specifications Appendix 19.1 Drilling template 19.2 Programming tables F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 5: Safety Notes

    Do not expose the unit to direct sunlight. Do not attempt to open the unit or the power adapter. For repairs, contact your Bosch dealer. When unplugging the unit from the power outlet, never pull on the power cord but always grip the power adapter.

  • Page 6: Features

    10 radio buttons. A signalling device can also be con- nected for persons with speech/hearing difficulties. The unit can also be programmed to initiate service calls (e.g. "meals on wheels") at the touch of a button. F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 7: Scope Of Delivery

    Carephone 52+ including battery Radio button including battery Power adapter Phone cord Getting started guide Quick programming guide Operating and programming manual Necklace and bracelet for fixing of the radio button Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 8: Unit Description

    8 en | Unit Description Carephone 52+ Unit Description Window Red emergency call button Grey S button Green sign in/sign out button Yellow activity monitor reset button F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 9: Functions

    If the time window is selected so that the activity monitor must be reset every day between 5 p.m. and 7 p.m., for example, the indicator lamp on the activity monitor reset button will light up during this time. Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 10: Sign In/sign Out Button

    You hear the sign in announcement. NOTICE! Emergency calls can be made from the emergency call button or radio button at any time - even after a sign out. This signs you in automatically. F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 11: The S Button

    The service call number is dialled. Unit status The S button lights up if there is a fault. To check the unit's status, press the S button. The unit's status is announced. Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 12: Radio Button

    CAUTION! The radio range between the radio button and the Carephone 52+ depends largely on the environment in which the devices are used. Test the range within your own home environment! F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 13: Taking Phone Calls

    Taking phone calls with the radio button To take a phone call with the radio button, press your radio button when the phone rings. To terminate the call, press your radio button again. Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 14: Emergency Call To A Call Centre

    A controller at the call centre takes your emergency call. You speak to the controller. The controller arranges for assistance to be dispatched depending on the circumstances. Wait until assistance arrives. F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 15: Emergency Call To A Private Phone

    The call can be extended by a further 3 minutes by pressing key 1. The call can be extended as often as required in this way. The call is terminated by press- ing key 0. Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 16

    Carephone 52+ dials the next number on the list. Remote activation of the relay output, only when programming step 72 is set to 6, see Section Activate output, page 38. Table 8.1 F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 17: Cleaning

    – If necessary, remove the upper shell of the Carephone 52+ and clean the spaces in between the buttons. The buttons can be detached by applying light pressure. Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 18: Device Acknowledgements

    Press the S button to repeat Standby mode Unit is ready Pre-alarm Cancel with stop button Connection Establish connection Speak Display for the (0.5s/0.5s) hearing-impaired Listen Listen (0.1s/2s) (display for the hearing-impaired) Table 10.2 F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 19

    Press the activity monitor reset button every day. Time window Press activity moni- active tor reset button now Pre-alarm activ- Cancel with activity (0.5s/0.5s) ity monitor monitor reset button Table 10.2 Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 20: Sound Signals Of The Carephone 52

    The activity monitor has been reset. Stop When the S button is pressed during the pre- alarm. The emergency call is cancelled. Table 10.4 F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 21

    Radio transmission monitoring faulty. The indica- tor lamp in the activity monitor reset button con- tinues to flash until the message has reached the centre. (X is the transmitter number) Table 10.5 Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 22: Installation

    The wall bracket stabilizes the Carephone 52+ and makes installation easier. F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 23: En | Table Of Contents Carephone

    Mount the Carephone 52+ by locating the screws in the holes provided in the base of the unit. Adjust the screw depth so that the unit can be mounted safely on the screws. Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 24: Connecting The Carephone

    Insert the plug on the telephone cord into the socket on the Carephone 52+. To prevent strain on the cord, feed it through the cable channel and then through the opening on the back of the unit. F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 25

    CAUTION! The backup battery will now be charged up. The battery is fully charged after 12 hours. The unit's full volume will not be available until the battery is fully charged. Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 26: Connection Configuration

    This also shuts down the battery. NOTICE! If you remove the power plug from your power outlet, the unit will announce a power failure. The unit will automatically switch over to battery operation. F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 27: Programming

    The centre can now upload preset parameters to your Care- phone 52+ or it can poll the unit's programming status and change it. NOTICE! Only a Bosch social alarm call centre can guarantee that all parameters will be correctly programmed. Programming with a programming unit The Carephone 52+ can be programmed with a programming unit and the associated PC software.

  • Page 28: Programming In Steps

    12.2 Programming in steps The whole programming process of the Carephone 52+ consists of individual programming steps. These programming steps are defined by Bosch and numbered 01 to 99. A programming step consists of a number and associated settings. Example: –...

  • Page 29: Opening The Unit

    0 to 9 Enter the programming data The unit announces the program step’s current content Cancels programming, saved data is not lost Switch off backup battery Reset factory defaults Table 12.1 Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 30: Programming Procedure

    To leave the programming mode, press the * key twice. To enter the PC-supported CPC-Programming mode (with APD or TSM Software), press P shortly a second time , the device will acknowledge with the Setup activated. F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 31: The Main Programming Steps

    In the programming step 01, it is possible to program the Carephone 52+ in a speechless mode, with selection 0. See Section 10.2 Sound signals of the Carephone 52+, page 20. Table 12.2 Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 32

    A time window for the activity monitor can only be remotely programmed with a programming unit or from the call centre. If a time window has been programmed, the unit announces 99. Table 12.2 F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 33

    Dial tone detection After entering the call number, you enter the call destination, e.g. the social alarm call centre. You can program: 0 = social alarm call centre (Bosch protocol) 3 = social alarm call centre (CPC protocol) 4 = to phone NOTICE! After programming step 19 the Carephone 52+ goes to programming step 10.

  • Page 34

    Enter a time between 0 and 99 minutes. 0 = Off. This function is only available with the Bosch RB2000 proto- col and the Bosch advanced ANT protocol. Confirmation with call When the repeated emergency call has been acknowledged, you can speak directly to the call centre.

  • Page 35

    In this programming step you can specify whether this will initiate a call to an emergency call partner. You can program: 0 = Without call 1 = With call Table 12.2 Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 36

    The Carephone 52+ plays the announcement: This is social alarm unit 123. The Carephone 52+ repeats the announcement according to the setting. You can program a setting from 1 to 9 for the required number. Table 12.2 F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 37

    This step is used to program the interval between automatic test calls from the Carephone 52+ to the social alarm call cen- tre in days. Select a setting between 0 and 28 days. 0 = Off Table 12.2 Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 38

    5 = Release with wireless transmitter 6 = Remote activation by call center 7 = Speak / Listen connection 8 = Prealarm 9 = Funct. 7+8 Prealarm with Speak / Listen connection Table 12.2 F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 39

    Carephone 52+ is turned off. Only the microphone stays active. The Care- phone will speak only during programming. You can program: 0 = Off 1 = On Table 12.2 Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 40

    The unit goes to programming step 82. You can now proceed to program the function of radio button 92, and so on. NOTICE! After programming step 89 the unit goes to programming step 80. Table 12.2 F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 41

    NOTICE! Make a note of the code numbers in the corresponding box in the programming table, see Section 19.2 Programming tables, page 50. WARNING! Resetting the unit will delete all registered radio buttons. Table 12.2 Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 42: Resetting The Carephone 52+ To Its Factory Settings

    The relay output and an external device are connected using a cord fitted with an RJ45 plug. This cord can be obtained ready pre-assembled with the required plugs. F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 43: Microphone/loudspeaker

    An external microphone or an external loudspeaker can be connected. Open the base of the Carephone 52+ by using a slotted screwdriver to release the battery cover from its clips (1) and press towards the left slowly (2). Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 44

    Release the clips on both sides und pull approx. 3-4 mm (4). When both clips are released, take the cover off. Connect the microphone or loudspeaker to the appropri- ate socket provided for it. Microphone socket. Loudspeaker socket. F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 45: Maintenance

    The radio button that is supplied with the unit uses the frequency specially reserved for social alarm calls in Europe. We, Bosch Security Systems, declare that the above mentioned products are manufactured in compliance with Annex II (Telephony) / IV (RF Transmission) of Directive 5/1999/EC.

  • Page 46: Replacing The Backup Battery

    Battery distributors are required by law to take back spent batteries; they must not be thrown away as household waste. Please return used (rechargeable) batteries to your specialist retailer or take them to a recycling centre intended for this purpose. F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 47: Technical Specifications

    (triggering groups) Max. number of radio buttons Volume settings 8 levels Emergency call protocols Multi-protocol enabled (RB2000, ANT, CPC and others, details on request) Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 48

    55 x 160 x 230 mm (H x W x D) Weight approx. 0.7 kg Housing colour similar to Pantone 430 U Protection class IP32 (IP30 wall mounting), IP67 radio button Ambient temperature range +5°C to +40°C Humidity F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 49: Appendix

    Appendix | en 49 Appendix 19.1 Drilling template The drilling template can be used if this document is printed to the correct scale. Correct print size should be DIN A5 (148 x 210 mm). Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 50: Programming Tables

    50 en | Appendix Carephone 52+ 19.2 Programming tables F.01U.031.884 V4 | 2009.03 Operating Manual Bosch Security Systems...

  • Page 51

    Carephone 52+ Appendix | en 51 Bosch Security Systems Operating Manual F.01U.031.884 V4 | 2009.03...

  • Page 54

    Bosch Security Systems Broadwater Park North Orbital Road Denham UB9 5HN PO Box 750 Uxbridge Ub9 5ZJ Phone: +44 (0) 1895 / 87 80 88 Fax: +44 (0) 1895 / 87 80 89 uk.securitysystems@bosch.com www.boschsecurity.co.uk © Bosch Security Systems, 2009...
