NTI RACKMUX-T15 Quick Start Setup Manual page 4

Once the terminal has been configured, press <F12> to prompt if the setup is to be saved. Select Yes by pressing space and
then press <F12> again to exit setup mode. If any IP addresses or Ethernet settings have been defined or edited, the terminal
must now be power cycled by using the switch at the rear of the terminal (ensure that no serially connected host is present prior to
power cycling the terminal). If the host server is connected and active, pressing return (if Auto Connect was set to OFF) should
now display a server login prompt.
Each of the defined servers may be selected by using <ALT> and a function key. For example to connect to a server which has
been defined as Remote IP Address 3, press <ALT> and <F4> (since the IP addresses are defined from 0 to 11 and the function
keys are labeled 1 through to 12).
When connecting to a server which is switched OFF or does not have telnet configured, a 10 second timeout will occur when the
server is selected (if Auto Connect is ON), or after pressing return when the server is selected (if Auto Connect is OFF). During
this 10 second timeout, it is not possible to select another server or enter setup.
Please ensure that the Page Length is set to '1*Lines' in the Display Setup (F1 in setup) to prevent possible problems when
switching between different servers.
Technical Specifications
Physical
Size (In.) WxDxH
Weight
Temperature
Humidity
Power Supply (Standard)
Power Supply (RACKMUX-T15-
48V model only)
Power Consumption
Cables Included
Rack mount kit
LCD Panel Specifications
Screen size
Resolution
Controls
Brightness
Contrast
Viewing Angle
Keyboard Specifications
Type
Terminal Emulation
Emulations
Character matrix
Screen size
Page length
Cursor
Modes
Color modes
Communication Ports
Serial port for host connection
Network port
Local printer ports
Serial baud rates
Data format
Serial handshake
Communications options
19x21.9x1.725
23.3 lbs.
0°~40°C operating, -20°~60°C storage
20% to 90% non condensing
110/220VAC, 50-60Hz
36-72VDC
60W (max), <25W (standby)
IEC Power cord (country specific), 1-1/2 foot 15HD VGA,6 foot DB9 female to DB25 male null modem cable
Included for Sun & most EIA 19" racks
15.1" visible diagonal
800x600
contrast, brightness, auto-adjust, color temperature
2
250cd/m (Nits)
500:1 (typical)
140° H / 125° V
83 key (US) / 84 key (Europe)
VT52, VT100, VT220, Console ANSI, PC TERM, TVI910+/925, WY-50+, WY-60, WY-100, WY-120, WY-325,
PCG Alpha
7x12 dot matrix in 10x16 cell with 3 dot descenders
80x25
1, 2, or 4 screens (multiple screen page length reduces maximum number of possible telnet sessions)
Blink or steady, block or underline
Full duplex, half duplex, block mode, half block mode
16 foreground and 16 background colors
One DB9M RS232 port
One RJ45 10Base-T Ethernet port
One DB25F Parallel and one DB9M RS232 port
50 to 115,200 bps
7 or 8 data bits with or without parity, 1 or 2 stop bits
XON/XOFF, XPC, and hardware DTR
Single RS232 server connection, or up to 12 Ethernet telnet sessions to predefined IP addresses. Both serial
and Ethernet connections can not be used concurrently.
4
Man030 Rev 7/30/2007
