Configuration
The terminal is delivered largely pre-configured. This section describes configuration for console serial or network connections.
Refer to the reference manual for details.
• Switch ON the terminal using the power switch located at the rear of the keyboard.
• Hold down the <ALT> key and then depress the <Esc> key to enter Setup Mode.
• Adjust the screen's brightness with the controls marked + and - located at the rear of the keyboard.
• If the screen image is not centered correctly, activate LCD auto-setup by pressing the 'Select' button at the rear of the keyboard.
This should only be done when displaying the terminal setup screen. To navigate the setup menus, use a function key to enter a
setup menu, and then use the arrow keys to highlight the field to be changed. Use the space key to change the value of a
parameter. Use <F12> to return to the top level menu, and <F12> again to leave setup mode. The user will be prompted at this
point if the setup parameters are to be saved for future sessions.
The terminal is delivered pre-configured with the following settings suitable for most RS232 serial console connections at 9600
baud using VT-100 emulation.
Disp SETUP Menu
Columns = Econ-80
Cursor = Blink Block
Screen Saver = Off
Lines = 24
Background = Dark
Page Length = 1 x Lines
Auto Page = Off
Width change clear = Off
ANSI Reverse = Off
Display= LCD
F4 Comm SETUP Menu
Baud rate = 9600
Data / Stop Bits = 8/1
Parity = None
Rcv Hndshake = Xon/Xoff
Xmt Hndshake = Xon/Xoff
Comm Mode = FDX
XPC Handshake = On
Printer Selection = Off
Multiple Sessions = Off
Ethernet Mode = Off
Auto Connect = Off
For use with an Ethernet connection the following parameters need to be configured:
• Display Setup (F1 in setup mode)
Page Length = 1*Lines (only required if 'Multiple Sessions=On')
• Communications Setup (F4 in setup menu)
Multiple Sessions = Off or On
Ethernet Mode = On
Auto Connect = Off or On
'Multiple Sessions=On' should be set if multiple telnet sessions are required.
'Auto Connect=On' is used to prevent the need to press return to establish a telnet connection.
• LAN Setup (F9 in setup mode)
Local IP Address = IP address of the terminal
Netmask = Netmask value for the network
Gateway = gateway address if required by the network
Remote IP 0 Address = IP address of first server Port = 23
Remote IP 1 Address = IP address of second server Port = 23
....
Remote IP B Address = IP address of twelfth server Port = 23
Term Type = Same as personality specified in General Setup menu
Ethernet Node ID = leave at default value
Note: If only one host is being connected to, all twelve Remote IP addresses and ports should be set to the same value.
Note: Eight separate telnet sessions are allowed if any columns other than Econ-80 is selected in Terminal Display Set-
up. If Econ-80 is selected, the Multiple Sessions option allows twelve concurrent telnet sessions to be used.
F2 General SETUP Menu
Personality = VT 100
Enhance = On
Status Line = Standard
Scroll Speed = Jump
Auto Scroll = On
End of Line Wrap = On
Rcvd CR = CR
Monitor = Off
Attribute = Char
F5 Misc SETUP Menu
Wprt Intensity = Dim
Wprt Reverse = Off
Wprt Underline = Off
Block End = US/CR
Ptr Baud rate = 38400
Ptr Data/Stop Bits = 8/1
Ptr Parity = None
Ptr Rcv Hndshake = Xon/Xoff
Ptr Xmt Hndshake = Xon/Xoff
Ptr Rcv = Off
3
F3 Keybd SETUP Menu
Keyclick = Off
Key Repeat = 5
Xmt Limit = None
Margin Bell = Off
Language = US
Keycode = ASCII
NRC = Off
Bell Volume = 2
NUM Start = Off
DEL Keypad = Dot/Del
F9 Lan Setup Menu
Local IP Address = {blank}
Netmask = {blank}
Gateway = {blank}
Remote IP 0..B Address ={blank}
Port 0...B = 23
Term Type = vt100
Ethernet Node ID = (default}
