- Page 1 PSBV200BT 300 Watts Bluetooth Sound Bar Systems W/ USB SD FM Radio& Wireless remote PSBV200BT STANDBY INPUT OWNER’S MANUAL PLEASE READ BEFORE OPERATING THIS EQUIPMENT WWW.PYLEAUDIO.COM...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS---------------------------------------------------------------1 PACKAGE CONTENTS----------------------------------------------------------------1 IMPORTANT SAFETY INSTRUCTIONS---------------------------------------2-3 FEATURES---------------------------------------------------------------------------------3 SPECIFICATIONS------------------------------------------------------------------------4 PLACING THE UNIT-------------------------------------------------------------------4 SYSTEM CONNECTIONS-------------------------------------------------------------5 1. CONNECT POWER SUPPLY------------------------------------------------5 2. CONNECT WITH PC & Mp3-----------------------------------------------5 3. CONNECT WITH TV/DVD----------------------------------------------------6 FRONT PANEL FUNCTIONS--------------------------------------------------------7 BACK PANEL FUNCTIONS----------------------------------------------------------7 REMOTE CONTROL FUNCTIONS-------------------------------------------------8 HOW TO USE THE REMOTE CONTROL-------------------------------------9 OPERATIONS----------------------------------------------------------------------------10 1. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Dangerous high voltages are present inside the enclosure. Do not open the cabinet, refer to qualified personnel only. The lighting flash with arrowhead symbol, within an equilateral riangle, is intended to alert user to the presence of uninsulated "dangerous voltage"... -
Page 4: Features
10. Unplug this apparatus during lightning storms or when unused for long period of time. 11. Power Source The product should be operated only from the type of power source indicated on the rear of the unit. 12. Overloading Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock. -
Page 5: Specifications
SPECIFICATIONS Power Supply---------- ----------------------------------------- AC:100~120V, 50/60Hz Peak RMS Output--------------------------------------------------------------------300W Input Sensitivity---------------------------------------------------------- 400mV±50mV S/N(A Weight)---------------------------------------------------------------------- 80dB Channel Separated Rate(1KHz)----------------------------------------------- 40dB Woofer Impedance----------------------------------------- -----------------------8 Ohm Tweeter and full range speaker Impedance----------------------------------4 Ohm THD(1KHz, 1W, 8Ohm)---------------------------------------------------------- 0.5% Frequency Response------------------------------------------------------ 20Hz-20KHz Dimensions(WxDxH)------------------------------------------------- 605x250x120MM Weight---------------------------------------------------------------------------------5.3KGS NOTE: Specifications are subject to change for improvement without prior notice. -
Page 6: System Connections
AC power. Do not operate with wet hands to Socket avoid electric shock. Power plug PSBV200BT STANDBY INPUT 2. CONNECT WITH PC/MP3 To listen to the sound source from PC (Computer) or MP3 Players, connect the unit with the external device as below: AUDIO IN DC:18V/2.5A... -
Page 7: Connect With Tv/Dvd
3. CONNECT WITH TV/DVD To listen to the sound source from Television and/or CD/VCR/DVD/DVR players, connect the unit with the external device as below: TV Video In TV Audio Out Audio In AUX 1 AUX 2 INPUT P C/MP3 SELECT Audio In DVD Video Out DVD Audio Out... -
Page 8: Front Panel Functions
FRONT PANEL FUNCTIONS PSBV200BT STANDBY INPUT 1. Power switch 2. Standby 3. Input 4. Play/pause/phone 5. LCD display 6. Power indicator STANDBY INPUT 7. Remote sensor 8. Pre / VOL- 9. Next / VOL+ 10. USB host 11. SD/MMC slot BACK PANEL FUNCTIONS DC :18 V/2 .5A... -
Page 9: Remote Control Functions
REMOTE CONTROL FUNCTIONS 1. STANDY-BY: Press to turn on the unit from standby model. Press again to turn STAND-BY MUTE the unit off(stand-by). INPUT 2. 3D: Press to turn on the surround TUNE- TUNE+ sound effect. Press again to turn it off. REPEAT MUTE: Press to turn off the sound... -
Page 10: How To Use The Remote Control
2. Effective scope of the remote control The remote control has an operating range which is less than 16 feet and at 30 degree angle left or right away from the system. PSBV200BT STANDBY INPUT Approx 16 feet NOTES:... -
Page 11: Operations
OPERATIONS 1. GENERAL OPERATION 1) Press the POWER button on the front panel of the unit to turn the unit to Standby mode. 2) Press the STANDBY button on the unit or remote control to power on the unit. 3) Press the INPUT button on the unit or remote control repeatedly to select the input sources to USB, CARD, FM radio, Blue, AUX1, AUX2, PC as desired. -
Page 12: Listen To Fm Radio
2. LISTEN TO FM RADIO Connect the supplied 3.5mm audio cable to FM ANT jack on the rear of the unit as the figure below. Extend the wire and relocate it to get the best reception. AUX 1 AUX 2 INPUT SELECT DC:18V/2.5A... -
Page 13: Sd/Usb Slot Operation
