Summary of Contents for Pyle PSBVWF300
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ACCESSORIES FRONT PANEL FUNCTIONS BACK PANEL FUNCTIONS SYSTEM MOUNTING DIAGRAM REMOTE CONTROL FUNCTIONS 1. CONNECT POWER SUPPLY 2. CONNECT WITH AUX IN 3. BLUETOOTH CONNECT 4.HOW TO OPERATE IN HD MODE 1). APPLICATION 2). FAVORITES 3). -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Dangerous high voltages are present inside the enclosure. Do Not open the cabinet, refer serving to qualified personnel only. The lighting flash with arrowhead symbol, within an equilateral triangle, is intended to alert user to the presence of un insulated “Dangerous voltage”... -
Page 4: Accessories
IMPORTANT SAFETY INSTRUCTIONS 9. Unplug this apparatus during lightning storms or when unused for a long period of time. 10. Power source The product should be operated only from the type of power source indicated on the rear of the unit. 11. -
Page 5: Front Panel Functions
FRONT PANEL FUNCTIONS 1. Power: Press turn power on, hold press to turn off. 2. Input: Repeat press to choose HD/AUX/BT mode. 3. Play: In Bluetooth mode press to play /Pause when playing Music or Press to listening phone when call coming 4. -
Page 6: System Mounting Diagram
SYSTEM MOUNTING DIAGRAM 1. Choose the position where you want to mount the sound bar, Mark as figure 1. Indicates. 2. USE A DRILL (7mm drill bit) to mark holes according to the marks in figure 1. 3. Put the plastic anchors into the hole and screw the wall plate onto the wall. ( NOTE . -
Page 7: Remote Control Functions
REMOTE CONTROL FUNCTIONS INSTRUCTIONS Pairing: press the "OK" button and the "2.4G/IR" button at same time, the LED will flicker, then plug USB dongle into the main unit's USB jack, the LED light will stop flicking, then pairing is a success. - Page 8 REMOTE CONTROL FUNCTIONS KEYBOARD OPERATION The keyboard is composed by 38 keys. Backspace: Delete previous character CAPS: Caps lock ENTER: confirm the operations SPACE: Spacebar ALT: Numeric character switch 2.4G USB Dongle 5. Parameter of the remote control a. Operation current: 20mA b.
-
Page 9: Connect Power Supply
SYSTEM CONNECTIONS Connect Power Supply Insert the power plug into a wall socket, make sure the voltage marked at the rear panel in the area of your AC/DC power adaptor. Do not operate with wet hands to avoid electric shock Connect with AUX in To listen the sound source from the DVD / TV you can use the RCA cable connecting with... -
Page 10: Bluetooth Connect
SYSTEM CONNECTIONS BLUETOOTH CONNECTION a. Press "INPUT" to enter "BT" mode then the unit will automatically show “0000" on display when connecting with your mobile Phone in first time. b. Use mobile phone Bluetooth search and choose "BT SPEAKER" enter "0000" for pairing with unit. -
Page 11: Application
SYSTEM CONNECTIONS 1). Applications: press menu to show all pre installed apps (See following photos) a. Uninstall APK Put the cursor on the App then press for choose and then press quickly edit mode Move cursor to choose if you want to add to Favorites list or uninstall app. b. -
Page 12: File Brower
SYSTEM CONNECTIONS 4). File Brower Choose " File Brower" you will enter following interface." Equipment, Video, Picture, Music, file" 5 sub menu for choose a. Equipment: you can choose the " Local memory, SD card or USB" b. Video : The default video player is a UHD player which supports play full HD movie, WMV/ASF/MP4/3GP/3G2M4V/AVI/MJPEG/RV10/ DicX/VC 1/ MPEG 2/MPEG 4/H.263/1280X720P/HD 30fps 1080p/ 720x480 DI 30fps/ blueray 3D@30fps 3840x1080@30fps decoding/... -
Page 13: Setting
SYSTEM CONNECTIONS e. File: Review all formats of files from local memory or SD card or USB. click "Menu" enter setting mode, you will see following interface. Under this mode you can edit as on PC. 5). Setting: a. Wi Fi: Click Wi Fi and keep "On" it will auto search the Wireless connection eg: Searched "... - Page 14 SYSTEM CONNECTIONS e. Storage: Setting the storage location. f. Apps: It will show all apps g. Users: Change settings for users as desired: simply click the menu and click "OK" for confirm the operations. The default language is English (USA), Language setting (see below pic) The unit has 60 languages to choose from.
-
Page 15: General Operation
SYSTEM CONNECTIONS Account: Account setting changes . Date &time setting (see picture) GENERAL OPERATION 1). Press the power button on the front panel of the unit to turn on. The unit will auto enter HD mode. 2). Repeat press the input to choose “AUX” or BT or HD mode. 3). - Page 16 "Are you sure you want to shutdown system" Click “CONFIRM" to turn power off. PRODUCT SPECIFICATIONS PSBVWF300 Smart SoundBar HD Digital Speaker System with Built in Android Computer, Wi Fi, Bluetooth, Microphone, USB & SD Card Readers, 300 Watt Built in Android Computer and Speaker System...
