Quick Start Guide
®
INSTEON Wireless Thermostat
Model: 2441ZTH

About INSTEON Wireless Thermostat

INSTEON Wireless Thermostat is a wireless, battery-operated, one-
day programmable, INSTEON-compatible thermostat. INSTEON
Wireless Thermostat includes a humidity sensor and the ability to
communicate via RF to other INSTEON devices and thermostats.
INSTEON Wireless Thermostat does not connect directly to the HVAC
(Heating, Ventilating and Air Conditioning) system. If you want to
control the HVAC system you need to install INSTEON Thermostat
and connect it directly to the HVAC system.
INSTEON Wireless Thermostat may be used as a standalone
INSTEON controller capable of controlling other INSTEON
responders. On its own, INSTEON Wireless Thermostat sends out notifications based on temperature status and can
even control standalone heaters and fans plugged into ApplianceLinc modules (#2456S3).
INSTEON Wireless Thermostats can also be linked to your main INSTEON Thermostat controller to create extra
temperature zones in your home. INSTEON Thermostat displays the temperature readouts from up to two linked
INSTEON Wireless Thermostats on its display.

Preparation

Proper installation of INSTEON Wireless Thermostat will be accomplished by following these steps. The product will
mainly be used in a tabletop stand; wall mounting is optional.
1)
Make sure the location that you have selected for INSTEON Wireless Thermostat will not be affected by daily
movement of sunlight or is not in direct line of sight of a nearby HVAC vent or fan
2)
Insert 2 AA batteries into INSTEON Wireless Thermostat
3)
Close the cover on INSTEON Wireless Thermostat
-
After a few seconds INSTEON Wireless Thermostat will display ambient temperature and humidity
-
Mode will default to OFF
-
Battery segment should show full with fresh batteries
-
Time will show default (12:00 PM) and become active
4)
Snap INSTEON Wireless Thermostat into the supplied tabletop stand or mount safely on a wall

Test Operation

INSTEON Wireless Thermostat communicates via radio frequency (RF) to the INSTEON Thermostat that controls the
HVAC system. Before adding INSTEON Wireless Thermostat as a controller of INSTEON Thermostat, perform the
following tests to familiarize yourself with INSTEON Wireless Thermostat. Keep in mind that INSTEON Wireless
Thermostat is presently a standalone device and you are not yet sending any INSTEON communications.
Note: While testing, the display will change but no HVAC operations will take place. INSTEON Wireless Thermostat
defaults to a 5-minute delay between modes and cycles.

Heating Mode Test

1) Press Mode button once to enter Heat mode
2) Tap Up or Down arrow button several times until setpoint is 1° above ambient
INSTEON Wireless Thermostat will call for Heat
"Heat" segment will change to "Heating," blink for 3 seconds and then go steady
No furnace activity will take place at this time--only display changes
3) Tap Up or Down arrow button until you reach a desirable heat temperature setpoint below ambient
