Specification - TTI TSX series Instruction Manual

OUTPUT SPECIFICATIONS
Voltage Range:
Current Range:
Output Voltage Setting:
Output Current Setting:
Output Mode:
Output Switch:
Output Terminals:
Sensing:
Output Impedance:
Output Protection:
OVP Range:
OVP Delay:
Load & Line Regulation:
Ripple & Noise:
HF Common Mode
Noise:
Transient Response:
Temperature Coefficient:
Protection Functions:
Status Indication:
METER SPECIFICATIONS
Meter Types:
Meter Resolution:
Meter Accuracy:
GENERAL
AC Input Voltage:
Power Consumption:
Operating Range:
Storage Range:
Environmental:
Size:
Weight:
Safety:
EMC:
2
Nominally 0-35V (35V/10A), Nominally 0-18V (18V/20A)
Nominally 0-10A (35V/10A), Nominally 0-20A (18V/20A)
By coarse and fine controls; 10mV setting resolution.
By single semi-logarithmic control; 10mA setting resolution.
Constant voltage or constant current with automatic crossover.
Electronic. Preset voltage and current displayed when off.
4mm terminals on front panel, screw terminals at rear.
Remote via rear panel screw terminals or direct via shorting strip (supplied).
<1mΩ in constant voltage mode.
>5kΩ in constant current mode (voltage limit at max.).
Forward protection by Over-Voltage-Protection (OVP) trip; maximum voltage
that should be applied to the terminals is 50V.
Reverse protection by diode clamp for reverse currents up to 3A.
10% to 110% of maximum output voltage set by front panel screwdriver
adjustment.
<200µs
<0.01% of maximum output for 90% load change or 10% line change.
<1mV rms typical in constant voltage
<3mA rms typical in constant current.
Typically <3mV rms, <10mV peak.
20µs to within 50mV of setting for 90% load change.
Typically <100 ppm/°C.
Overvoltage trip. Regulator overtemperature. Sense miswiring.
Output off lamp. Constant voltage mode lamp
Constant current mode lamp. Trip message on display.
Dual 4 digit meters with 12.5mm (0.5") LEDs. Reading rate 4Hz.
10mV, 10mA
Voltage 0.2% of reading ± 1 digit, current 0.5% of reading ± 1 digit.
110V-120V AC or 220V-240V AC ± 10%, 50/60Hz. Installation Category II.
600VA max.
5°C to +40°C, 20% to 80% RH.
–40°C to +70°C.
Indoor use at altitudes up to 2000m, Pollution Degree 2.
210 x 140 x 385mm (W x H x D), half rack width x 3U height
(optional rack mounting kit available)
5kg.
Complies with EN61010-1
Complies with EN61326-1

Specification
