Pro-Form PETL12711.0 User Manual page 9

5. Identify the Left and Right Base Covers (82, 83).
Slide the Left Base Cover onto the Left Upright
(89). Slide the Right Base Cover onto the Right
Upright (90). Do not press the Base Covers
into place yet.
Identify the Left and Right Upright Covers (79,
80). Slide the Left Upright Cover onto the Left
Upright (89). Slide the Right Upright Cover onto
the Right Upright (90).
6. Cut the plastic tie in the Left Handrail (88) and
the Right Handrail (not shown). If necessary,
press the 5/16" Cage Nuts (31) back into place
(only one is shown).
Identify the Left Handrail (88) and hold it near
the Left Upright (89). Insert the Upright Wire
(81) through the bracket on the bottom of the
Left Handrail. Pull the Upright Wire out of the
end of the Left Handrail.
5
89
79
82
6
81
31
Tie
89
9
90
80
83
88
