CEILING FAN

OWNER'S MANUAL
READ AND SAVE THESE INSTRUCTIONS
MODEL: BARLEY TWIST
FAN RATING AC 120V. 60Hz
CUL LISTED MODEL : AC-418

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BARLEY TWIST and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Savoy BARLEY TWIST

Summary of Contents for Savoy BARLEY TWIST

  • Page 1: Ceiling Fan

    CEILING FAN OWNER'S MANUAL READ AND SAVE THESE INSTRUCTIONS MODEL: BARLEY TWIST FAN RATING AC 120V. 60Hz CUL LISTED MODEL : AC-418...

  • Page 2: Tools And Materials Required

    1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items; a. Blade set (5) b. Hanger bracket assembly c.

  • Page 3: Safety Rules

    3. SAFETY RULES 1. To reduce the risk of electric shock, insure 9. To avoid personal injury or damage to the electricity has been turned off at the fan and other items, be cautious when circuit breaker or fuse box before working around or cleaning the fan.

  • Page 4: Mounting Options

    4. MOUNTING OPTIONS If there isn't an existing CUL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the Outlet box building structure. Use appropriate fasteners and building materials.

  • Page 5: Hanging The Fan

    5. HANGING THE FAN Hanger bracket REMEMBER to turn off the power. Follow the steps below to hang your fan properly: Ceiling canopy Step 1. Remove the decorative canopy bottom cover from the canopy by turning the cover counter clockwise. (Fig. 5) Canopy cover Step 2.

  • Page 6: Installation Of Safety Support

    6. INSTALLATION OF SAFETY SUPPORT An additional safety support is provided to Hanger bracket Safety cable prevent the fan from falling. Secure the safety cable to the ceiling joist with screw and washer, as illustrated in Figure 9. Figure 9 7.

  • Page 7: Finishing The Installation

    Step 3. (Figure 12) Receiver to House Supply Wires Electrical Connections: Outlet box Connect the black (hot) wire from the ceiling to the black wire marked "AC in L" White (neutral) Black (hot) f r o m t h e r e c e i v e r . C o n n e c t t h e Green or bare white(neutral) wire from the ceiling to the copper (ground)

  • Page 8: Attaching The Fan Blades

    9. ATTACHING THE FAN BLADES Caution: Remove the screws from the motor support plate, discard the screws and motor support plate. Step 1 Attach the blade to the blade bracket using the screws and fiber washers as shown in Figure 14. Start screw into bracket.

  • Page 9: Installing The Light Kit

    11. INSTALLING THE LIGHT KIT N O T E : B e f o r e s t a r t i n g i n s t a l l a t i o n , d i s c o n n e c t t h e p o w e r b y t u r n i n g o f f the circuit breaker or removing the fuse at fuse box.

  • Page 10: Installing The Battery

    13. INSTALLING THE BATTERY Install 9 volt battery (included), to prevent damage to transmitter, remove the battery if not used for long periods. (Fig. 14. OPERATING INSTRUCTIONS Restore power to ceiling fan and test for Figure 18 proper operation. A. HI, MED, and LOW buttons: These three buttons are used to set the fan speed as follows: HI= high speed...

  • Page 11: Troubleshooting

    Cool weather - (Reverse) An upward airflow moves warm air off the ceiling area as shown in Fig. 21. This allows you to set your heating unit on a cooler setting without affecting your comfort. Figure 21 15. TROUBLESHOOTING Problem Solution Fan will not start.
