Linear Power 1002 Owner's Manual And Installation Manual

F O R
Your new Linear Power™1002
combining reliability, high power, low distortion, and freedom from external noise.
When properly installed, it will give long and faithful service. When combined with
other high quality components, it will be the heart of a superb system. Thank you
for purchasing a Linear Power™ Product.
POWER SUPPLY: Self oscillating for reliability and efficiency. The transformer is
epoxy dipped for extreme vibration resistance.
OUTPUT STAGES: Transformer less, direct coupled and fully complimentary.
Output transistors are high current and low distortion TO-3 Devices in the 1002
operating at a fraction of their limitations. Total power dissipation potential of the
output transistors is well over 500 watts.
PROTECTION: Our stable amplifier design is made virtually indestructible by two
separate forms of protection. First is an all-new Thermal Protection Circuit, which
is designed to prevent damage from high frequency oscillations or excessive
ambient temperature. The second form of protection protects the amplifier from
short circuits in the installation. Both circuits are automatically resetting.
CONSTRUCTION FEATURES: The infinitely variable input sensitivity control
permits optimal signal matching for lowest noise and lowest distortion with
virtually any source. All components used are rated for at least 150% of their
intended use, and are mounted on double-sided fiberglass epoxy circuit boards.
T H E L O
MODEL 1002
(1984-MSRP $289.00)
OWNER'S MANUAL AND
INSTALLATION GUIDE
