Linear Power 5002 Owner's Manual And Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

™
F O R
T H E
L O V E
O F
M U S I C
MODEL 5002
©
(1986-MSRP $899.00)
OWNERS MANUAL AND

INSTALLATION GUIDE

INTRODUCTION
Several new features appearing for the first time in these two LINEAR POWER™
amplifiers include: true compatibility to 2 ohm and 4 ohm speaker impedances,
switchable Bridged Mono capability, a turn on delay to avoid speaker damage,
control circuitry for an optional cooling fan, and the new "Dynamics Improving
Processor
" circuit. The "Dynamics Improving Processor
" provides a well
©
©
controlled and precise redistribution of power in the bass region to help
overcome the factors in the mobile environment that work against the auto-sound
installer: poor speaker placement, the masking effect of a car in motion, and the
natural tendency of most speakers to roll off too soon in the low bass region. The
net result is accurate musical reproduction that you can take with you. Isn't that
what it's all about?
TECHNICAL DESCRIPTION
POWER SUPPLY: Self oscillating for reliability and efficiency. The transformer is
epoxy dipped for extreme vibration resistance. Banks of high-speed TO-3
switching transistors provide massive current reserves. LINEAR POWER™
amplifier design incorporates an unregulated power supply for increased dynamic
headroom and efficiency.
OUTPUT STAGES: Transformerless, direct coupled and fully complimentary.
Output transistors are high current and low distortion TO-3 devices, operating at
a fraction of their limitations. The TO-3 output stages of these amplifiers will
deliver a significant increase in power into 2-ohm stereo loads. Amplifier reliability
is accomplished by operating the output transistors at 50% of their maximum
rating even into a 2-ohm stereo load. In 4-ohm stereo, the output devices, in the
5002™, work at less than 30% of their design capabilities as engineered by
Motorola. Linear Power™ products are seriously over built!
PROTECTION: Our stable amplifier design is made virtually indestructible by two
protection circuits. One is a precision thermal protection circuit, which prevents
damage from high frequency oscillation, or an excessive ambient temperature.
The second protection circuit is a current sensing device guarding against
instantaneous abnormalities, such as short circuits. Both circuits are
© 2008 Linear Power, Inc. - ALL RIGHTS RESERVED
1
LINEAR POWER™ is a trademark of Linear Power, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5002 and is the answer not in the manual?

Questions and answers

Related Manuals for Linear Power 5002

Summary of Contents for Linear Power 5002

  • Page 1: Installation Guide

    50% of their maximum rating even into a 2-ohm stereo load. In 4-ohm stereo, the output devices, in the 5002™, work at less than 30% of their design capabilities as engineered by Motorola. Linear Power™ products are seriously over built! PROTECTION: Our stable amplifier design is made virtually indestructible by two protection circuits.
  • Page 2 Only glass epoxy circuit boards are used. QUALITY CONTROL: In-house construction of critical components like transformers and chassis, as well as total assembly, allows Linear Power to maintain uniform quality. 100% of the finished units are tested, then burned in for four hours, and tested again.

  • Page 3: Bridged Mono Operation

    The center pin of the RCA plug is ALWAYS the positive input connection. 7. As shipped from the factory, the Model 5002 will be set up as a normal ©...

  • Page 4: Operation / Adjustment

    © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.

  • Page 5: General Troubleshooting

    WARNING Your new LINEAR POWER™ amplifier, when used in conjunction with many of the efficient speaker systems on the market today, can produce sound pressure levels that are considered harmful to your hearing.

  • Page 6: Types Of Noise

    The entire wiring harness can become contaminated if a portion of it runs along side the alternator to battery cable. © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.
  • Page 7 The best capacitors to use are .5mfd 25v bypass capacitors for the coil, as well as any accessory motors, and .1mfd 100v ceramic disc © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.

  • Page 8: Service Or Repair

    To obtain modification, service or repair, please contact our ONLY Authorized LINEAR POWER™ Product Service Center: T.I.P.S. INC. 3455 Lanell lane, Pearl, MS 39208 (601) 932-8477 E-mail: ray@tipsinc.net © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.

  • Page 9: Specifications

    Slew rate in volts per microsecond 16 V per μS Input Sensitivity (at rated output - min/max gain) 200mV - 5Volts Max Power Consumption Idle/4-ohm/2-ohm 2A/77A/90A © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.
  • Page 10 3 4 5 5 L A N E L L L A N E, P E A R L, M S 3 9 2 0 8 (6 0 1) 9 3 2 – 8 4 7 7 © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED...
