I
F O R T H E L O V E O F M U S C
MODEL 1001SW
©
(1995-MSRP $375.00)
OWNER'S MANUAL AND

INSTALLATION GUIDE

INTRODUCTION

Your new LINEAR POWER™ amplifier employs a sophisticated design
combining reliability, high power, low distortion, and freedom from external noise.
When properly installed, it will give long and faithful service. When combined with
other high quality components, it will be the heart of a superb system.

1001SW TECHNICAL DESCRIPTION

The Model 1001SW is a dedicated subwoofer amplifier with a built-in variable
©
crossover. This unit is 2 ohm or 4 ohm capable, delivering 100 watts of power
into a 4-ohm load and 200 watts into a 2-ohm load.
The unregulated pulse width modulated driven power supply of the 1001SW
©
uses mosfet switching transistors for high current capacity and improved
efficiency. Over current and thermal protection circuitry are used to insure long
life and reliable operation. The speaker output is also internally fused to protect
against any mishaps that might occur in wiring or under extreme loading
conditions.
The amplifier section of the 1001SW utilizes an all-discrete design to insure low
©
noise and distortion levels. The output transistors are capable of producing high
currents, yet only operate at a fraction of their full rating.
The 12dB/octave crossover is switchable between 60,80 and 110Hz, with high
pass outputs for use in multi-amp systems. The gain control is infinitely variable
which permits optimal signal matching for lowest noise and lowest distortion with
virtually any source.
© 2008 Linear Power, Inc. - ALL RIGHTS RESERVED
1
