F O R
T H E
L O V E
O F
M U S I C
MODEL 3002
(1986-MSRP $699.00)
OWNERS MANUAL AND
INSTALLATION GUIDE
INTRODUCTION
Several new features appearing for the first time in this LINEAR POWER™
amplifier; new in the 3002
include, true compatibility to 2 ohm and 4 ohm
©
speaker impedances, switchable Bridged/Mono capability, a turn on delay to
avoid speaker damage, control circuitry for an optional cooling fan, and the new
"Dynamics Improving Processor©" circuit. The "Dynamics Improving
Processor©"(DIP switch) provides a well controlled and precise redistribution of
power in the bass region to help overcome the factors in the mobile environment
that work against the auto-sound installer: poor speaker placement, the masking
effect of a car in motion, and the natural tendency of most speakers to roll off too
soon in the low bass region. The net result is accurate musical reproduction that
you can take with you. Isn't that what it's all about?
TECHNICAL DESCRIPTION
POWER SUPPLY: Self oscillating for reliability and efficiency. The transformer is
epoxy dipped for extreme vibration resistance. Banks of high-speed TO-3
switching transistors provide massive current reserves. LINEAR POWER™
amplifier design incorporates an unregulated power supply for increased dynamic
headroom and efficiency.
OUTPUT STAGES: Transformerless, direct coupled and fully complimentary.
Output transistors are high current and low distortion TO-3 devices, operating at
a fraction of their limitations. The TO-3 output stages of these amplifiers will
deliver a significant increase in power into 2-ohm stereo loads. Amplifier reliability
is accomplished by operating the output transistors at 50% of their maximum
rating even into a 2-ohm stereo load. In 4-ohm stereo, the output devices in the
3002
work at less than 30% of their design capabilities as engineered by
©
Motorola. Linear Power™ products are seriously over built!
© 2008 Linear Power, Inc. - ALL RIGHTS RESERVED
1
LINEAR POWER™ is a trademark of Linear Power, Inc.
Advertisement
Table of Contents
Related Manuals for Linear Power 3002
Summary of Contents for Linear Power 3002
- Page 1 (1986-MSRP $699.00) OWNERS MANUAL AND INSTALLATION GUIDE INTRODUCTION Several new features appearing for the first time in this LINEAR POWER™ amplifier; new in the 3002 include, true compatibility to 2 ohm and 4 ohm © speaker impedances, switchable Bridged/Mono capability, a turn on delay to avoid speaker damage, control circuitry for an optional cooling fan, and the new "Dynamics Improving Processor©"...
- Page 2 Only glass epoxy circuit boards are used. QUALITY CONTROL: In-house construction of critical components like transformers and chassis, as well as total assembly, allows LINEAR POWER™ to maintain uniform quality. 100% of the finished units are tested, then burned in for four hours, and tested again.
- Page 3 It should be connected to the battery's positive terminal, or as close to the battery as possible. Use the fuse holder and fuse provided, and replace only with the same size fuse. Model 3002 uses a SC35 ©...
-
Page 4: Bridged/Mono Operation
“4” and press them firmly back onto lugs marked “2”. This will allow the amplifier to operate into 2-ohm stereo load on each channel, or a 4-ohm bridged load when used in bridged mono mode. © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc. -
Page 5: Operation / Adjustment
WARNING Your new LINEAR POWER™ amplifier, when used in conjunction with many of the efficient speaker systems on the market today, can produce sound pressure levels that are considered harmful to your hearing. -
Page 6: General Troubleshooting
(noise) station under the hood. This noise is often transmitted to the vehicle's wiring harness. © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc. - Page 7 RCA connector, at the amplifier end, to a good ground on the vehicle. This will effectively short circuit the ground loop. © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.
-
Page 8: Service Or Repair
To obtain modification, service or repair, please contact our ONLY Authorized LINEAR POWER™ Product Service Center: T.I.P.S. INC. 3455 Lanell Lane, Pearl, MS 39208 (601) 932-8477 E-mail: ray@tipsinc.net © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc. -
Page 9: Specifications
3 4 5 5 L A N E L L L A N E, P E A R L, M S 3 9 2 0 8 (6 0 1) 9 3 2 – 8 4 7 7 © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED... - Page 10 © 2008 Linear Power, Inc. - ALL RIGHTS RESERVED LINEAR POWER™ is a trademark of Linear Power, Inc.
