AUTO-SCANNING WITH DIGITAL CONTROL
LCD COLOR DISPLAY MONITOR
MultiSync
USER'S GUIDE
For future reference, record the serial
number of your display monitor in the
space below:
SERIAL No.
The serial number is located on the
rear cover of the monitor.
®
LCD1800
Internet Home Page: http://www.necmitsubishi.com/
Supplying Windows 95/98 INF File download service,new products
information, etc.
™
Advertisement
Table of Contents
Related Manuals for NEC MULTISYNC LCD1800TM
Summary of Contents for NEC MULTISYNC LCD1800TM
- Page 1 AUTO-SCANNING WITH DIGITAL CONTROL LCD COLOR DISPLAY MONITOR ® ™ MultiSync LCD1800 USER’S GUIDE For future reference, record the serial number of your display monitor in the space below: Internet Home Page: http://www.necmitsubishi.com/ SERIAL No. The serial number is located on the Supplying Windows 95/98 INF File download service,new products rear cover of the monitor.
- Page 2 (2) this device must accept any interference received, including interference that may cause undesired op- eration. For questions regarding this declaration, contact: NEC-Mitsubishi Electronics Display of America, Inc. 1250 N. Arlington Heights Road, Suite 500 Itasca, IL 60143 or, call...
- Page 3 Below you will find a brief summary of the environmental requirements met by this product. The complete environmental criteria document may be ordered from: TCO Development SE-114 94 Stockholm, Sweden Fax: +46 8 782 92 07 Email (Internet): development@tco.se Current information regarding TCO’99 approved and labelled products may also be obtained via the Internet, using the address: Congratulations!
-
Page 4: Table Of Contents
X/Open Company Limited. is a U.S. registered mark. NERGY NEC is registered trademark of NEC Corporation. All other trademarks or registed trademarks are property of their respective owners. © 2000 NEC-MITSUBISHI Electronics Display of America, Inc. - 1-1 -... -
Page 5: Introduction
INTRODUCTION FullScan ™ Capability Congratulations on your purchase of the MultiSync Allows you to use the entire screen area in most LCD1800 ™ high resolution color LCD monitor. resolutions, significantly expanding image size. This guide tells you how to connect, adjust and care for your MultiSync LCD1800 monitor. -
Page 6: Ipm
• With some resolution, even if it meets the condition found. The latest drivers may be downloaded from the above, the screen is not expanded fully to the screen "Support" section of the NEC-MITSUBISHI Website lo- area. cated at: •... -
Page 7: Accucolor Control Function
® 1.10 AccuColor Control Function 1.13 Unpacking The following color modes are available: After you unpack the box you should have all of the items 1. sRGB: sRGB mode dramatically improves the color indicated in Figure 1. Save the box and packing materials fidelity in the desktop environment by a single stan- in case you ship or transport the monitor. -
Page 8: Quick Operation Chart
1.15 Quick Operation Chart To summarize the steps in connecting your computer and adapter with MultiSync LCD1800 ™ color LCD monitor and setting the necessary controls and switches, refer to the chart below. Connect the power cord to the MultiSync LCD1800 color LCD monitor and the signal cable between the MultiSync LCD1800 and the computer. -
Page 9: Part Name
PART NAME Control Names See Figures 3 and 4 for the location of the user controls, indicator and connectors. Each part is identified by number and described individually. FRONT REAR SIGNAL A/B SELECT ADJUST Figure 4 OSD OFF Figure 3 Function CABLE COVER (UPPER) POWER SWITCH: A push-on / push-off switch for... -
Page 10: Installation And Connection
INSTALLATION AND CONNECTION Signal Cable Connection On the back of the monitor are three plug-in connec- tions: one for the DC power connection and others for The attached video signal cable provides a D-SUB-15P the video signal connection. connector for the VGA compatible analog RGB outputs on your computer. -
Page 11: 3.2.2 Connecting To An Apple Macintosh Computer
3.2.2 Connecting to An Apple Macintosh Computer Figure 6 shows the signal cable and Macintosh Adapter to the video port in an Apple Macintosh. 1. Power off, both the monitor and the computer. 2. Connect the 15-pin (D-SUB-15P) end of the Macintosh Adapter to the straight 15-pin connector on the Macintosh video port on the computer or on the video board. -
Page 12: Auto Setup Function
AUTO SETUP OSM(On Screen Man- FUNCTION ager) FUNCTIONS Two methods, "AUTO SETUP" and "OSM ™ Adjustment" How to Adjust the Screen are available for adjusting the screen. (For the "OSM Adjustment", see 5. OSM (On Screen Manager) FUNC- The monitor has an OSM (On Screen Manager) function. TIONS.) Conduct the "AUTO SETUP"... -
Page 13: Adjustment Items
Adjustment Items Press "ALL RESET" to restore to the factory preset level. Press buttons together, to restore to the factory preset level. Set data by each timing. Set data does not change by the changing of the signal timing. Group Press the Minus Button: Press the Plus Button: Item... -
Page 14: Control Lock Mode Operation
Press "ALL RESET" to restore to the factory preset level. Press buttons together, to restore to the factory preset level. Set data by each timing. Set data does not change by the changing of the signal timing. Group Item Press the Minus Button: Press the Plus Button: Item Icon... -
Page 15: Troubleshooting
Before calling your Authorized Product Support, please check that the items below are properly connected or set. TROUBLESHOOTING In case of using a non-standard signal, please check the pin assignments and the signal timing of your computer with the specification outlined in 7. SPECIFICATIONS. ITEMS TO CHECK LOCATION PROBLEM... -
Page 16: Specifications
SPECIFICATIONS LCD Panel 46cm/18.1" Color TFT Panel Type Active Matrix Resolution 1280 dots x 1024 lines Pixel Pitch 0.28mm LCD MODULE Color Filter R, G, B vertical stripe type Face Finishing Anti-glare, Hard Coated Viewing Angle ±80°(Horizontal/Vertical) CR Video 0.7Vp-p analog RGB Sync Sync.on Green or Separated H,V or Composite sync. -
Page 17: Limited Warranty
Product for a specific purpose or application must be parts or unit. determined by consumer and is not warranted by NEC- This warranty gives you specific legal rights and you may MITSUBISHI.
