CHOICE RSTAT 7
INSTALLATION AND USER INSTRUCTIONS
DIGITAL, RF DELUXE PROGRAMMABLE ROOM THERMOSTAT
Features
• Wireless radio communication between thermostat
and receiver box
• 24hr, 5/2 day or 7 day programmable
• 3 off preset & non adjustable programmes
• 1off free user adjustable programme
• Programmable in 30min steps
• 3 off temperature levels, Comfort, Comfort 2,
Economy plus Frost Protection
• Battery powered (with low-power indicator)
• Automatic or Manual Mode selection
• Standby Mode with Frost Protection
• Holiday Mode with Frost Protection
• Temporary temperature override
• Timed temperature override
• Automatic Summer/Winter time change
• Optimisation and Anticipation functions
• Heating, Air Conditioning or both mode options
• Large clear backlit display showing programme profile for current day
• Temperature adjustment range 5 to 30°C
This programmable room thermostat has been designed to bring you comfort and energy economy.
It allows you to program and regulate your heating system at 3 temperature levels:
• Comfort
• Comfort 2
• Economy
plus
• Frost Protection
It also enables you to program and regulate air-conditioning at 2 temperature levels:
• Comfort
• Economy
A large backlit LCD on the thermostat provides clear feedback for the user and in response to program
settings, transmits RF signals to the wall mounted receiver installed next to the boiler that is being
controlled.
Each day is conveniently split into 48 time periods for you to programme according to your lifestyle.
+
