Freezer Storage

FREEZER BASKET REMOVAL
IMPORTANT NOTE: Unload freezer baskets before removal.
Model BI-36F and side-by-side models: To remove the
basket, pull it out until it stops. Behind the bottom two
corners of the front face of the basket are metal clips.
Pull these clips toward the front of the basket and lift and
rotate the basket up. Refer to the illustration below.
To reinstall, push the drawer slides back into the freezer.
Align the basket with the slides and push the basket
straight back onto the slides until it stops. Press
downward on the front of the basket to engage the basket
clips with the slides.
IMPORTANT NOTE: To remove the baskets from models
BI-36S, BI-42S or BI-42SD, the basket must be raised
and pulled through the opening in the door liner after
disengaging the basket from the slides.
IMPORTANT NOTE: If models BI-36F or BI-36S are limited
to a 0° opening, it may be necessary to remove the
basket and shelf above in order to remove the basket.
For over-and-under models: To remove the upper freezer
basket, lift up on the front and pull forward to release the
basket. To remove the lower freezer basket, lift the basket
directly upward and out. Refer to the illustration below.
To reinstall the lower freezer basket, insert the basket into
the four corner retainers. To reinstall the upper freezer
basket, position the basket onto the slide rails. Slide the
basket towards the back until you hear a click.
Freezer basket (BI-36F and
side-by-side models).
Freezer basket (over-and-
under models).
ICE CONTAINER REMOVAL
Model BI-36F and over-and-under models: To remove the
ice container, pull the freezer basket or the freezer drawer
out until it stops and lift the ice container out.
Models BI-36S, BI-42S and BI-48S: To remove the ice
container, pull the container forward until it stops. Next, lift
the container to clear the carrier assembly along the back
edge of the container. Once the container has cleared the
assembly, continue to pull forward and out. If the door is
limited to a 0° opening, repeat the procedure, but when
lifting the ice container out, pivot the right side of the
container toward you and out. This will allow the ice
container to clear the door. Refer to the illustration below.
Models BI-42SD and BI-48SD: To remove the ice
container, pull the container out part of the way, then
rotate the right side of the container as you continue to
pull the container out. Refer to the illustration below.
Ice container (BI-36S, BI-42S
and BI-48S).
subzero.com
Ice container (BI-42SD and
BI-48SD).
