Built-In Use & Care
Ice and Water Dispenser
WATER DISPENSER OPERATION
To operate the water dispenser for models BI-42SD and
BI-48SD, set a glass on the water grille of the glasswell,
and press and hold the WATER key pad on the glasswell
until the glass is filled.
The first time you use the water dispenser, purge the water
system and storage tank for three minutes. This will clear
any air in the system, along with foreign material in the
new plumbing connection.
Initially, for water to dispense properly, the WATER key
pad must be pressed and held until water flows from the
dispenser. You may have to hold the key pad for 60
seconds for water to fill the internal reservoir tank.
IMPORTANT NOTE: The chilled water reservoir tank is
mounted inside the refrigerator section. It will take several
hours to chill the water to the refrigerator temperature
during the original fill or after a lot of water is used.
DISPENSER LIGHTS
For dispenser models, there are three lighting states that
can be cycled by pressing the LIGHT key pad on the
glasswell; all lights OFF, all lights ON (blue key pad and
white glasswell) and key pad lights ON only.
During water or ice dispensing, all lights will illuminate
until dispensing is complete, then lights will return to their
previous state.
DISPENSER WATER GRILLE
For dispenser models, a water grille at the base of the
glasswell will catch and evaporate small spills. Because
there is no drain in this area, do not pour water into the
water grille. To clean the area, remove the water grille by
pressing the front left corner of the grille and lifting it out.
LOCK
For dispenser models, the lock feature is used to prevent
unintended ice and water dispensing. When the dispenser
is locked, all key pads on the glasswell are deactivated to
allow cleaning or to prevent small children from using the
dispenser.
To activate the lock feature, hold down the LIGHT key pad
on the glasswell until the key pad lights flash once and the
red LOCK icon is illuminated (approximately five seconds).
The lights will remain in the state they were in before the
lock feature was activated.
To deactivate the lock feature, hold down the LIGHT key
pad until the key pad lights flash once and the red LOCK
icon is no longer illuminated (approximately five seconds).
The lights will remain in the state they were in before the
lock feature was deactivated.
Limit continuous ice and water dispenser operation to
seven minutes or less, to avoid damaging the equip-
ment.
