Built-In Use & Care
Electronic Control System
The electronic control system of your Sub-Zero built-in
unit monitors and accurately displays temperatures within
one degree of your preset temperature. It also monitors
operation of the unit and lets you know if there's a
problem. The control center is located in the refrigerator
section of all models, except model BI-36F where it is in
the freezer section. Refer to the illustration below.
TEMPERATURE CONTROL
Your new built-in unit was thoroughly inspected and
tested before it was shipped from the Sub-Zero factory.
Temperatures are preset at 38°F
section and 0°F in the freezer section. Tempera-
(-18°C)
tures are displayed in the control center display panel.
For combination units, there are two sets of COLDER
and WARMER key pads on the control center, one for the
refrigerator section and the other for the freezer section.
Models BI-36R, BI-36RG and BI-36F have only one set of
COLDER and WARMER key pads.
To adjust the temperature in either section, press the
COLDER or WARMER key pads on the control center.
Refer to the illustration below.
CONTROL PANEL
DISPLAY
Control center display panel.
in the refrigerator
(3°C)
COLDER / WARMER
KEY PADS
Temperature adjustment.
The temperature ranges are -5°F
in the freezer section, and 34°F
refrigerator section. It is normal for temperatures to fluctu-
ate slightly, depending on external influences such as an
open door, the degree of humidity and room temperature.
IMPORTANT NOTE: Always allow 24 hours for the unit to
reach the temperature you set.
POWER
All Sub-Zero built-in models feature a POWER key pad on
the control center. This key pad will turn off all electrical
power to the unit. When the power is off, the OFF indica-
tor light will be visible in the control center display panel.
This POWER key pad means you don't have to shut off
power at the circuit breaker or wall receptacle. The key
pad can be used during service or extended vacations.
12
to +5°F
(-21°C) (-15°C)
to 45°F in the
(1°C) (7°C)
