Freezer Baskets; Ice Container; Freezer Storage - Sub-Zero BI-30UG Use And Care Manual

STORAGE

Freezer Storage

FREEZER BASKETS

BI-36F and side-by-side models
until basket stops. Pull the two metal clips located behind
the bottom two corners of the basket forward, then lift up
and out. Refer to the illustration below. To reinstall, push
drawer slides in. Align the basket with slides and push
back until it stops. Press down on the front of the basket to
engage slides.
IMPORTANT NOTE: To remove for models BI-36S, BI-42S,
BI-42SID and BI-42SD, the basket must be raised
and pulled through the opening in the door liner after
disengaging.
Over-and-under models |
freezer baskets, lift up and out. Refer to the illustration
below. To reinstall, insert the lower basket into the four
corner retainers. Position the upper basket onto the side
rails and slide back until it clicks.
BI-36F and side-by-side models. Over-and-under models.
| To remove, pull forward
To remove the upper and lower

ICE CONTAINER

BI-36F and over-and-under models
tainer forward until it stops, then lift out.
Side-by-side models | To remove, pull container forward
until it stops, then lift to clear the carrier assembly along the
back. Pull forward and out. Refer to the illustration below.
Dispenser models | To remove, pull container out partially,
then rotate and pull out. Refer to the illustration below.
Side-by-side models.
| To remove, pull con-
Dispenser models.
|
subzero.com 7
