USER GUIDE SUPPLEMENT
CONTENTS
2002, Shure Incorporated
27B8655 (BA)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
UHF Wireless System
KK (838-862 MHz)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
5
6
6
7
7
7
Printed in U.S.A.
Advertisement
Related Manuals for Shure UHF KK
Summary of Contents for Shure UHF KK
-
Page 1: Table Of Contents
........2002, Shure Incorporated Printed in U.S.A. -
Page 2: Specifications
SPECIFICATIONS RF Carrier Frequency Range 838–862 MHz Working Range 152.4 m (500 ft), minimum, under typical conditions; 487.6 m (1600 ft ) line of sight NOTE: Actual working range depends on RF signal absorption, reflection and interference Audio Frequency Response 50 to 15,000 Hz, ±2 dB NOTE: Overall system frequency response depends on the microphone element Gain Adjustment Range... - Page 3 Overall Dimensions U1: 92.2 mm L x 64.7 mm W x 24.2 mm D (3–29/32 x 2–35/64 x 61/64 in.) U2/58:254 mm L x 50.8 mm Dia. (10 x 2 in.) U2/BETA 58: 254 mm L x 53.2 mm Dia. (10 x 2–3/32 in.) U2/87:228.6 mm x 49.2 mm Dia.
- Page 4 MICROPHONE U1 MIC JACK BOARD ELEMENT 500 Ω +5 V 27 pF 20K Ω 500 Ω AUDIO 27 pF GROUN NOTE: LAVALIER MIC TIES PINS 3 AND 4 TOGETHER; GUITAR CABLE DOES NOT. U1L (LEMO 4 PIN) MIC JACK BOARD 499 Ω...
-
Page 5: Furnished Accessories
U4S and U4D Receiver Input Connector: Antenna Power Input Network Interface Connector Type: 25–Pin D 50 Ω Actual –– –– Impedance: Nominal Input –95 to –30 dBm 90–230 VAC, CMOS Logic Level: 50/60 Hz Maximum Input +6 dBm 230 VAC, 50/60 Hz ––... -
Page 6: Optional Accessories
OPTIONAL ACCESSORIES Instrument Adapter Cable (U1) ........WA302 4–Pin Female Miniature Connector TA4F (U1) . -
Page 7: Frequency Selection Guide
FREQUENCY SELECTION GUIDE The Shure UHF Wireless System is designed for maximum flexibility and versatility in a variety of applications. Up to 16 Shure UHF Wireless Systems can be operated simultaneously in a single installation using the frequency compatibility groups. Please contact Shure Incorporated if you need additional information or assistance in frequency selection and setup. - Page 8 SHURE Incorporated Web Address: http://www.shure.com 222 Hartrey Avenue, Evanston, IL 60202–3696, U.S.A. Phone: 847-866–2200 Fax: 847-866-2279 In Europe, Phone: 49-7131-72140 Fax: 49-7131-721414 In Asia, Phone: 852-2893-4290 Fax: 852-2893-4055 Elsewhere, Phone: 847-866–2200 Fax: 847-866-2585...
