Owner's Manual
®
Bonaire Evaporative Cooler
Please keep this important manual in a safe place. It is the owner's responsibility to ensure that regular maintenance is
carried out on this Air Conditioning product. Failure to do so will void all guarantees beyond statutory and legal requirements.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bonaire and is the answer not in the manual?

Questions and answers

Related Manuals for BONAIRE Bonaire

Summary of Contents for BONAIRE Bonaire

  • Page 1 Owner’s Manual ® Bonaire Evaporative Cooler Please keep this important manual in a safe place. It is the owner’s responsibility to ensure that regular maintenance is carried out on this Air Conditioning product. Failure to do so will void all guarantees beyond statutory and legal requirements.
  • Page 2 OOLER Introduction BONAIRE ® Thank you for purchasing a quality Bonaire Evaporative Cooler. We care about your safety and would ask you to spend a few minutes reading these simple instructions before installing or operating this product. Safety ! Read carefully all of these instructions prior to installing and operating the unit.
  • Page 3 ONAIRE INDOW OOLER Installation BONAIRE ® TOOLS / MATERIALS REQUIRED FOR INSTALLATION Drill (Power or Cordless) Drills for drilling pilot holes into window frame 1/8" (3.2mm) Drill - or appropriate for size of Screw used. Phillips Head Screw Driver 3/4" Philips Head Screws for affixing Window Infill Panel Silicone for sealing Window Infill Panel 1/2”...
  • Page 4 ONAIRE INDOW OOLER Installation BONAIRE ® • Ensure that the unit is installed level in the two positions illustrated prior to fixing the cooler. Sill Spacer • Use the two ‘Wallmate’ screws provided to fix the cooler to the outside of the house if a ‘stucco-type’...

  • Page 5: Water Connection

    ONAIRE INDOW OOLER Installation BONAIRE ® WATER CONNECTION • Install a water supply line from the closest cold water point to the cooler. The water supply line must be installed by a licensed person and must conform to all standards, state & Local regulations.
  • Page 6 ONAIRE INDOW OOLER Installation BONAIRE ® • Close window against unit. Measure the gap of the opening & cut the in-fill panel to fit in the gap left. • The infill panel supplied is for use with hopper style window only.

  • Page 7: Operation Instructions

    ONAIRE INDOW OOLER Operation Instructions BONAIRE ® COOLER OPERATION Before Starting • Always ensure that there is another open window or door through which the air can exhaust to other parts of the house. • Ensure that the filters are kept clean.
  • Page 8 ONAIRE INDOW OOLER Maintenance BONAIRE ® Before commencing any maintenance work on your unit, ensure it is disconnected from the power supply. Note: It is essential that your evaporative air conditioner is maintained in accordance with this manual. Failure to do so will affect the life of the product and reduce the level of efficiency.
  • Page 9 ONAIRE INDOW OOLER Maintenance BONAIRE ® GENERAL Filter Pads Visually check CEL-dek pads for damage or blockage. Gently hose down pads from both sides to remove any build up of salts, dust and pollen. In dusty areas more regular cleaning is recommended.

  • Page 10: Spare Parts

    ONAIRE INDOW OOLER Spare Parts BONAIRE ® Description Part Number Filter Retainer Clips 6280134SP Louvre Assembly 6280103SP Filter Pad Set 6280116SP Motor Mounting Brackets 6282006SP Motor 6281610SP Fan Retaining Clip 6280804SP 6280806SP Control Knob 6201609SP Switch 904322SP Capacitor 6280133SP Float Valve Assembly...

  • Page 11: Wiring Diagram

    ONAIRE INDOW OOLER Wiring Diagram BONAIRE ® Accessories Winter Cover Inside View. Optional Winter Cover Instructions The Durango optional winter cover has been Location Fin. designed to provide you with a simple method to seal the unit from winter draughts.
  • Page 12 ONAIRE INDOW OOLER Installation and Operation Manual BONAIRE ® Call Climate Technologies Service Call Climate Technologies Service...
  • Page 13 An authorised Climate Technologies service provider must carry out warranty service. For Metro Service only ring the numbers below.
  • Page 14 • If there is no certificate of compliance for plumbing or electrical, Climate Technologies reserves the right to refuse service on non-compliant installations. • No responsibility will be accepted for outside elements such as pests, animals, pets and vermin that may cause damage to the unit.
  • Page 15 ONAIRE INDOW OOLER Warranty (Australia Only) BONAIRE ® PERIODS OF WARRANTY – YEARS EVAPORATIVE AIR CONDITIONING RESIDENTIAL COMMERCIAL Parts Labour Parts Labour ** Filter pads are a consumable item and therefore are not covered by the above warranty periods. PROOF OF PURCHASE It is important that the name of the Dealer or Retailer from whom you purchased your product and the name of the installer is recorded on this page.
  • Page 16 All rights reserved. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording or by any information storage and retrieval system, without prior permission in writing from Climate Technologies.
