Technical specifications

MONO INPUT
MIC (channel 1 and 2) .................................... XLR-3 female, electronically balanced
Signal level ............................................ -50 dB @ 600ohm variable
Impedance............................................. 3 kohm nominal
Input noise ............................................. < -117 dB (IHF-A)
Headroom.............................................. 33 dB
STEREO INPUTS
LINE (channel 2)............................................. Cinch
Signal level ............................................ -14 dB @ 600ohm variable
Input impedance .................................... 10 kohm nominal
Input noise ............................................. < -80 dB (IHF-A)
Channel separation................................ > 65 dB @ 1 kHz
LINE 1/ 2 (channel 3..6) .................................. Cinch
Signal level ............................................ 0 dB @ 600ohm variable
Input impedance .................................... 10 kohm nominal
Input noise ............................................. < -86 dB (IHF-A)
Channel separation................................ > 65 dB @ 1 kHz
TONE CONTROL
EQUALISER CHANNEL 1/ 2
High ....................................................... 10 kHz 15 dB, Shelving
Low........................................................ 80 Hz 15 dB, Shelving
EQUALISER MASTER
High ....................................................... 12 kHz 15 dB, Shelving
Mid......................................................... 1400 Hz 12 dB, Bell
Low........................................................ 50 Hz 15 dB, Shelving
JUKEBOX INPUT
Input voltage .......................................... 5..24 VDC (make- or break-contact also possible)
OUTPUTS
BALANCED MASTER (XLR) .......................... +6 dB balanced/ 600ohm/ variable
MASTER OUT A/ B (Cinch) ............................ 0 dB unbalanced/ 600ohm/ variable
PHONES (6,3 mm TRS Jack)......................... 0,3 W @ 4ohm/ Impedance 4..32ohm
FREQUENCY RESPONSE
MIC TO MASTER ........................................... 80 Hz...25 kHz -1 dB
ALL OTHER INPUTS TO MASTER ................ 20 Hz...25 kHz -1 dB
THD + N ......................................................... 0,005 % nominal
GENERAL
BUILT-IN POWER SUPPLY
Mains voltage......................................... 220...240 VAC / 50 Hz
Power consumption ............................... 10 W
SIZE AND WEIGHT
Front ...................................................... 483 x 221 mm (B x H) = 19", 5HE
Cutout.................................................... 445 x 217 mm (B x H)
Cabinet depth ........................................ 105 mm without connectors
Weight ................................................... 3,7 kg Net.
Dateq Audio Technologies B.V. reserves the right to amend specifications without notice.
