Summary of Contents for Dateq XTC
- Page 1 USER MANUAL...
-
Page 3: Safety Instructions
Dateq XTC Manual Safety instructions Safety instructions All safety instructions, warnings and operating instructions must be read first. All warnings on the equipment must be heeded. The operating instructions must be followed. Keep the operating instructions for future reference. The equipment may never be used in the immediate vicinity of water; make sure that water and damp cannot get into the equipment. -
Page 4: Product Support
The master also has a chinch output. The XTC has a monitor out, a Sub low output for operation of an (active) low speaker and a second headphone connection. - Page 5 Dateq XTC Manual Introduction Dateq XTC: X-mix with Three Channels The design of the latest Dateq DeeJay mixer arose from the work (dance) floor itself. The result: a compact, 4-channel mixer, Technics sized, with all the facilities required for the perfect mix.
- Page 6 Mounting the XTC The XTC can be used as stand-alone or built-in (mounted). The housing fits in an opening of 250 x 336 x 107mm (W x H x D). See also the drawings below. When mounting reckon with the...
- Page 7 Dateq XTC Manual Connections XTC Connector board The connections for all audio in- and outputs are situated at the backside of the XTC. The on/off switch and the fuse are also located here. L / R Master Balanced Outputs (XLR 3-pins male)
- Page 8 FUSE Mains fuse. Dimension 5x20mm (small), 315mA fast. MAINS Mains cable. Before connecting the XTC for the fist time, see if your XTC is meant for the mains voltage in your country (label on the connector board at the rear).
- Page 9 Dateq XTC Manual Operation DJ-channel This channel is designed to connect a microphone and is equipped with volume control and a 2-way tone control. Above the gain control is a BNC-connection for an optional 12V lamp. GAIN (Volume preset) Determines the volume of the microphone.
- Page 10 Operation Output section The output section consists of a precise 2 x 30 segments LED bar meter and volume controllers for the various outputs of the XTC. METER Indication of the Master or Cue level. An operation level of approximately 0dB is normal.
-
Page 11: Technical Specifications
Dateq XTC Manual Technical Specifications Technical specifications MONO INPUT DJ MIC ............XLR-3 female, electronically balanced Signal level ..........-54 dB @ 600 variable Impedance..........3 k nominal Input noise..........< -107 dB (IHF-A) Headroom..........+20 dB STEREO INPUTS PHONO (X/T/C)..........Cinch Signal level ..........-42 dB @ 47 k variable Input impedance........47 k / 25pF nominal...
