- Page 1 CREW CREW SER MANUAL...
-
Page 3: Safety Instructions
Dateq Crew Manual Safety instructions Safety instructions All safety instructions, warnings and operating instructions must be read first. All warnings on the equipment must be heeded. The operating instructions must be followed. Keep the operating instructions for future reference. The equipment may never be used in the immediate vicinity of water; make sure that water and damp cannot get into the equipment. -
Page 4: Product Support
C U E Front Front The DATEQ Crew is a seven channel 19-inch mixer. It is highly suitable for use in pubs, dancing- schools, conference centres etc. The Crew is equipped with three microphone inputs and 11 stereo-line inputs. Channel 1 has a talk-over circuit to improve the speech intelligibility. This circuit, which is triggered by the microphone signal from channel 1 (i.e. - Page 5 Installing the Crew The Crew is designed to be mounted in a 19-inch rack and is three units high. The cabinet fits into an opening of 445 x 132 x 110 mm (W x H x D). See also the dimensioned drawings below.
- Page 6 Dateq Crew Manual Connections Crew Connectorboard At the rear all the audio in and outputs can be found, just as the euro-mains connector (with built in mains-fuse) and the optional zone outputs with the volume control inputs. Made by Input 7...
- Page 7 MASTER A/ B Unbalanced outputs on cinch connectors. These can be used to connect the Crew to an amplifier or recorder. These outputs are equipped with relays to prevent connected equipment from ‘plopping’ when the unit is being switched on and off.
- Page 8 Dateq Crew Manual Connections Zone volume control By means of this input the volume of an external zone can be adjusted. The volume control can be connected in two different ways: Supplying an external voltage When a voltage is supplied between the tip and the shielding of one of the cinch-connectors the volume will be attenuated (for both the left and the right channel).
- Page 9 Dateq Crew Manual Operation Microphone with TalkOver (1) A microphone can be connected to this channel (at the front, or at the rear). The channel has a gaincontrol, a dual equaliser and an input-selector. GAIN M i c M i c...
- Page 10 60mm fader which can be used to control the volume of this channel. Master sectie (A and B) The Crew has two identical mastersections (A and B). Each section has a dual equaliser, balance and gain control and an after-fader-listen function. HIGH HIGH High tone control.
- Page 11 Dateq Crew Manual Operation Various HIGH POWER POWER Mains switch. PHONES Headphones volume control with a stereo headphones connector. The selected CUE- signal can be heard with the headphones M u l t i - z o n e M u l t i - z o n e...
-
Page 12: Technical Specifications
Front............483 x 132 mm (W x H) = 19”, 3HE Cutout ............445 x 132 mm (W x H) Cabinet depth........... 110 mm without connectors Weight............3.5 kg Net. Dateq Audio Technologies B.V. reserves the right to amend specifications without notice...
