Power Craft PCd-2400IK User Manual & Warranty

24v cordless hammer drill
Hide thumbs
Table of Contents

Advertisement

Quick Links

hammer drill
After Sales Support
Now you have purchased a Power Craft
product you can rest assured in the
knowledge that as well as your 3 year
parts and labour warranty you have
the added peace of mind of dedicated
helplines and web support.
24V cordless
User Guide & Warranty
AFTER SALES SUPPORT
UK HELPLINE NO
0905-1460005
IRELAND HELPLINE NO
WEB SUPPORT
www.servotool.eu
Model nuMber: PCd-2400IK
ArT. no: CdM6105
(£ 0,06 /min.)
1520-932626 (E 0,15 /min.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCd-2400IK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Power Craft PCd-2400IK

Summary of Contents for Power Craft PCd-2400IK

  • Page 1 24V cordless hammer drill User Guide & Warranty After Sales Support AFTER SALES SUPPORT Now you have purchased a Power Craft product you can rest assured in the UK HELPLINE NO 0905-1460005 (£ 0,06 /min.) knowledge that as well as your 3 year IRELAND HELPLINE NO 1520-932626 (E 0,15 /min.)

  • Page 2: Table Of Contents

    Introduction Machine specifications Safety instructions Assembly Operation Maintenance Exploded view Spareparts list Warranty Notes UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...

  • Page 3: Introduction

    By doing so you now have the assurance and peace of mind that comes with purchasing a product made by one of Europe’s leading manufacturers. All products brought to you by Power Craft are manufactured to the highest standards of performances and safety, and, as part of our philosophy for customer service and satisfaction, are backed by our comprehensive 3 Year Warranty.

  • Page 4: Machine Specifications

    Sound pressure (Lpa) 86+3 dB(A) Sound power (Lwa) 97+3 dB(A) Vibration value Drilling in metal 3.2 + 1.5 m/s Drilling in concrete 15.6 + 1.5 m/s Product information Fig.A UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...
  • Page 5 9 Drill bits 1 Bitholder 1 Case 1 Operating instructions 1 Quick start guide 1 After sales support Check the machine, loose parts and accessories for transport damage. UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...

  • Page 6: Safety Instructions

    Do not use in rain. Never throw batteries into an open fire. In the event of a disruption in power, the transformer is not dangerous. UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...
  • Page 7 9. Never try to repair the charger or battery block by yourself. Repairs must always be carried out by a qualified specialist, otherwise an accident may occur. UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...
  • Page 8 If it becomes necessary to replace the power cable, this must be carried out by the manufacturer or an authorized representative in order to prevent safety risks. UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...
  • Page 9 Hold the machine at the insulated gripping surfaces as the belt grinder may hit its own power cord. Damaging a live cable may make metal machine parts live, which may lead to an electric shock. UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...
  • Page 10 Electric tools are dangerous, if they are used by inexperienced persons. Maintain the machine with care. Please check whether the movable parts are perfectly operational and do not jam, whether parts have UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...
  • Page 11 Cutting accessory contacting a “live” wire may make exposed metal parts of the power tool “live” and could give the operator an electric shock. UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...

  • Page 12: Assembly

    • Before connecting the charger, ensure that the outer surface of the battery block or tool is clean and dry. Before connecting the charger, ensure the surface of the battery and tool are clean and dry. UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...
  • Page 13 • Slide the side handle over the drill chuck. • Turn the side handle to the desired position. • Tighten the side handle by rotating it clockwise. UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...

  • Page 14: Operation

    • Set the direction of rotation switch (1) to position ´R´ for tightening screws. • Set the direction of rotation switch to position ´L´ for loosening screws. UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...
  • Page 15 • When you release the ON/OFF switch (Fig. A, 2, page 4), the drill chuck stops immediately and does not continue to run. • Turn the direction of rotation switch ((Fig. A, 1, page 4) to the center in UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...
  • Page 16 • The red coloured bar illuminates: the battery is discharged and must be recharged. UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.heltec.eu Web Support: www.servotool.eu Model Number: PCS-360/2LK Model Number: PCD-2400IK...
  • Page 17 The ultimate capacity of the battery is reached after 4 to 5 charging/discharging cycles. UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.heltec.eu Web Support: www.servotool.eu Model Number: PCS-360/2LK Model Number: PCD-2400IK...

  • Page 18: Maintenance

    Faulty and/or discarded electrical or electronic machines have to be collected at the appropriate recycling locations. Do not dispose of in house hold waste UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...
  • Page 19 UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...

  • Page 20: Spareparts List

    Description Position 400525 Chuck screw ( M5 X 20 ) 409929 Peacock keyless chuck 400527 Switch 400528 Movable buttons 45, 46 CDA6034 Battery 400529 Fast charge UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...

  • Page 21: Warranty

    Quotes as well as repairs after warranty period are to be paid for in all cases. Ensure the product is sent well packed as no responsibility can be accepted for items lost or damaged in transit. This warranty does not affect your statutory rights. UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...

  • Page 22: Notes

    Notes UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...
  • Page 23 Notes UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PCD-2400IK...
  • Page 24 24V cordless hammer drill PCD-2400IK If you are requested by the manufacturer to return the item for repair please complete the enclosed section and send it together with your product and your receipt (proof of purchase) to the service address shown below.
