- Page 1 Anleitung BDP 600 13.11.2001 13:54 Uhr Seite 1 Operating Instructions Electronic Hammer Drill PDM 600 Art.-Nr. : 42.586.45...
- Page 2 Anleitung BDP 600 13.11.2001 13:54 Uhr Seite 2 Please read the operating instructions meticulously and pay particular attention to the safety instructions. Keep the operating instructions together with the drill.
-
Page 3: Technical Data
Seite 3 G The level of noise at the work- Scope of delivery Caution G The PDM 600 is not designed place may exceed 85 dB(A). In package this case you will need to intro- for the operating of auxiliary... - Page 4 Anleitung BDP 600 13.11.2001 13:54 Uhr Seite 4 On/Off switch: To switch on: Press switch A Continuous operation: Lock switch A with locking button B To switch off: Press switch A briefly The speed is varied by applying more or less pressure on switch A. You can preselect the speed by turning the knurled screw in switch Push the slide switch to posi-...
- Page 5 Anleitung BDP 600 13.11.2001 13:54 Uhr Seite 5...
- Page 6 Anleitung BDP 600 13.11.2001 13:54 Uhr Seite 6 Replacement parts drawing PDM 600 Art.-Nr. 42.586.45, I.-Nr. 91016...
- Page 7 Anleitung BDP 600 13.11.2001 13:54 Uhr Seite 7 Replacement parts list PDM 600 Art.-Nr. 42.586.45, I.-Nr. 91016 Item Designation Replacement Part No. Screw 42.586.00.01 Chuck 42.586.00.02 Spindle 42.586.00.03 O-ring 42.586.00.04 Sliding bearing 42.586.00.05 Locating disk 42.586.00.06 Special gear wheel 42.586.00.07 Compression spring 42.586.00.08...
-
Page 8: Warranty Certificate
Anleitung BDP 600 13.11.2001 13:54 Uhr Seite 8 WARRANTY CERTIFICATE The guarantee period begins on the sales date and is valid for 1 year. Responsibility is assumed for faulty construction or material or funcitional defects. Any necessary replacement parts an necessary repair work are free of charge.
