Original instructions & Warranty
After Sales Support
Now you have purchased a Power Craft
product you can rest assured in the
knowledge that as well as your 3 year
parts and labour warranty you have
the added peace of mind of dedicated
helplines and web support.
1050W
HAMMER DRILL
AFTER SALES SUPPORT
UK HELPLINE NO
IRELAND HELPLINE NO
WEB SUPPORT
Model number: PKB-1050/2
ART.NO: PDM6021
0905-1460005 (£ 0,06 /min.)
1520-932626 (E 0,15 /min.)
www.servotool.eu
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Power Craft 1050W
Summary of Contents for Power Craft 1050W
- Page 1 1050W HAMMER DRILL Original instructions & Warranty AFTER SALES SUPPORT After Sales Support Now you have purchased a Power Craft UK HELPLINE NO 0905-1460005 (£ 0,06 /min.) product you can rest assured in the IRELAND HELPLINE NO 1520-932626 (E 0,15 /min.)
-
Page 2: Table Of Contents
Contents Contents Introduction Machine data Safety instructions Mounting accessories Operation Maintenance Parts list Exploded view Warranty UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PKB-1050/2... -
Page 3: Contents
Introduction Congratulations on choosing to buy a Powercraft Product By doing so you now have the assurance and peace of mind that comes with purchasing a product made by one of Europe’s leading manufacturers. All products brought to you by PowerCraft are manufactured to the highest standards of performances and safety, and, as part of our philosophy for customer service and satisfaction, are backed by our comprehensive 3 Year Warranty. -
Page 4: Machine Data
Machine data Technical specifications Mains voltage 230 V~ Mains frequency 50 Hz Power input 1050W No-load speed 0 - 1000 / 0 - 2800/min Impact rate Drilling 0 - 16000/min Hammer drilling 0 - 44800/min Max, drill bit diameter Wood... -
Page 5: Safety Instructions
Safety instructions 1. On/off switch 2. Lock-on button 3. Speed adjustment wheel 4. Forward/reverse switch 5. Switch for mechanical speed 6. Switch for drilling/hammer drilling 7. Chuck 8. Main grip 9. Auxiliary grip 10. Depth stop Explanation of the symbols Read instructions carefully. -
Page 6: Safety Instructions
Safety instructions General safety instructions Warning! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “power tool” in all of the warnings listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 7 Safety instructions 3) Personal safety a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of carelessness while operating power tools may result in serious personal injury.
- Page 8 Safety instructions e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tools operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools. f.
- Page 9 Safety instructions Electrical safety Always check that the voltage on the machine corresponds to the voltage on the rating plate. Also check that your mains voltage corresponds to the input voltage of the battery charger. The machine is double insulated; therefore no earth wire is required.
- Page 10 Safety instructions Vibration level The vibration emission level stated in this instruction manual has been measured in accordance with a standardised test given in EN 60745; it may be used to compare one tool with another and as a preliminary assessment of exposure to vibration when using the tool for the applications mentioned •...
- Page 11 Mounting accessories Before assembly, always switch off the machine and remove the mains plug from the mains. Mounting and removing the drill bit Fig. B The machine is suitable for use of the following drill bits: • Wood (HSS) • Metal (HSS) •...
-
Page 12: Mounting Accessories
Mounting accessories Mounting and removing the auxiliary grip Fig. C Mounting • Loosen the auxiliary grip (9). • Slide the auxiliary grip (9) over the chuck (7). • Turn the auxiliary grip (9) to the required position. • Tighten the auxiliary grip (9). Removing •... - Page 13 Operation Switching on and off (Fig. A) • To switch on the machine, press the on/off switch (1). The further the on/ off switch (1) is pressed, the higher the speed of the machine. • To switch the machine to continuous mode, keep the on/off switch (1) pressed and simultaneously press the lock-on button (2).
-
Page 14: Operation
Operation Setting the operating mode (Fig. A) Do not change the operating mode during use. • Set the switch (6) to position ”A” for drilling. • Set the switch (6) to position ”B” for hammer drilling. Hints for optimum use •... -
Page 15: Maintenance
Maintenance Make sure that the machine is not live when carrying out maintenance work on the motor. These machines have been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper machine care and regular cleaning. Cleaning Keep the ventilation slots of the machine clean to prevent overheating of the engine. -
Page 16: Parts List
Parts list Part no Description Position 702887 Auxiliary handle 702888 Drill chuck + bolt left 2 + 3 702889 Carbon brush set 702890 Switch UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PKB-1050/2... -
Page 17: Exploded View
Exploded view UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PKB-1050/2... - Page 18 UK Helpline 0905-1460005 • Ireland Helpline 1520-932626 Web Support: www.servotool.eu Model Number: PKB-1050/2...
-
Page 19: Ec Declaration Of Conformity
Warranty EC DECLARATION OF CONFORMITY We Ferm B.V. Lingenstraat 6, 8028 PM Zwolle, The Netherlands declare that the design and construction of the following machine, in the form supplied by us, comply with the requirements of the appropriate EC directives. Product Description: HAMMER DRILL Model: PKB-1020/2 Appropriate EC directives: 2006/42/EC, 2006/95/EC, 2004/108/EC, 2002/95/EC, 2002/96/EC... -
Page 20: Warranty
1050W HAMMER DRILL PKB-1020/2 If you are requested by the manufacturer to return the item for repair please complete the enclosed section and send it together with your product and your receipt (proof of purchase) to the service address shown below.
