Contents and Features

Contents
Important Safety Instructions . . . . . . . . . . . .3-4
Contents and Features . . . . . . . . . . . . . . . . . .5
Features Chart . . . . . . . . . . . . . . . . . . . . . . .6
Cautions for Safe Operation . . . . . . . . . . . . . . .7
Part Names and Functions . . . . . . . . . . . . . .8-10
Connections . . . . . . . . . . . . . . . . . . . . . . . .11
Mounting the Lens . . . . . . . . . . . . . . . . . . . .12
Concerning Auto-Iris Lenses . . . . . . . . . . . . . .13
External Device Connections . . . . . . . . . . . . . .14
Flange-back Adjustment . . . . . . . . . . . . . . . .15
Installation of Camera . . . . . . . . . . . . . . . . .16
Menu Operation . . . . . . . . . . . . . . . . . . . .17-18
Language and Camera Identification Settings . . .19
Exposure Settings . . . . . . . . . . . . . . . . . .20-24
White Balance Settings . . . . . . . . . . . . . . .25-27
Day/Night Setting . . . . . . . . . . . . . . . . . . . .28
Motion Detector Setting (MOTION DET) . . . .29-30
Page 5
Privacy Masking Setting . . . . . . . . . . . . . . . .31
Special Menu Settings . . . . . . . . . . . . . . .32-36
RS-485 Protocol . . . . . . . . . . . . . . . . . . . . .37
Specifications . . . . . . . . . . . . . . . . . . . . .38-39
Features
This color video camera is designed for use in mon-
itoring system.
• High resolution and high sensitivity with a 1/ 3
inch Super HAD CCD (Charge Coupled Device)
• Line Lock when using AC 24V power.
• C/CS Mount
5
