Owner's Guide and Installation Manual
Advertisement
Table of Contents
Related Manuals for Hunter 42834-01
Summary of Contents for Hunter 42834-01
- Page 1 For reference, also attach your receipt or a copy of your receipt to the manual. __________________________________________ Model Name __________________________________________ Model No. __________________________________________ Date Purchased __________________________________________ Where Purchased Form# 42834-01 20100127 ©2010 Hunter Fan Co. Type 2A Models Type 2A Models Type 2A Models Owner’s Guide and Installation Manual...
-
Page 2: Table Of Contents
• READ THIS ENTIRE MANUAL CAREFULLY BEFORE BEGINNING INSTALLATION. SAVE THESE INSTRUCTIONS. • Use only Hunter replacement parts. • To reduce the risk of personal injury, attach the fan directly to the support structure of the building according to these instructions, and use only the hardware supplied. - Page 3 To install and use the accessories, follow the instructions included with each product. For quiet and optimum performance of your Hunter fan, use only Hunter speed controls. CAUTION: To reduce the risk of personal injury, attach the fan directly...
-
Page 4: Getting Ready
• Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •... -
Page 5: Installing The Hanger Bracket
Tighten the screws into the 9/64” pilot holes; do not use lubricants on the screws. Do not over tighten. Flat Washer 42834-01 • 01/27/10 • Hunter Fan Company Hanger Bracket Canopy Screw Isolator 3”... -
Page 6: Assembling The Fan
Ground Wire Step 3-3 #8-32 x 1” Screw 42834-01 • 01/27/10 • Hunter Fan Company 3-1. Position the square hanger so that the green ground wire attached to the square faces out of the large opening in the metal bracket. -
Page 7: Support System
4-8. Return to the fan so you can complete the fan wiring. Steps 4-2 – 4-3 Steps 4-4 – 4-5 3mm (1/8") Support Brace Outlet Box Braided Ceiling Cable 42834-01 • 01/27/10 • Hunter Fan Company Step 4-1 Steps 4-6 – 4-7... -
Page 8: Wiring The Fan
5-7. Spread the wires apart, with the grounded wires on one side of the outlet box and the ungrounded wires on the other side of the outlet box. 42834-01 • 01/27/10 • Hunter Fan Company 5 •Wiring the Fan Wire... -
Page 9: Installing The Motor Housing
Rotate the fan housing to situate the screws in the narrow ends of the keyholes. 6-3. Install the two remaining canopy screws into the holes in the fan housing and into the hanger bracket. Securely tighten all screws. -
Page 10: Assembling The Blades
Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 7-1. Install the grommets into the blades by hand. 7-2. Place each blade between a blade iron and medallion. Install three blade screws to attach the medallion to the blade iron. Repeat for all blades. -
Page 11: Completing Your Installation With A Light Fixture
8 • Completing Your Installation With a Bowl Light Fixture Your Hunter fan comes with an integrated light fixture assembly. WARNING: Use only the light fixture supplied with this fan model. 8-1. To attach the upper switch housing, partially install two housing assembly screws into the switch housing mounting plate. - Page 12 190 Watts. Exceeding that limit or the marked limit on this product may result in fire hazard or improper operation. 42834-01 • 01/27/10 • Hunter Fan Company Steps 8-6 – 8-7 Lower Switch Housing...
- Page 13 8-8. First install B10 candelabra bulbs (60 Watt Maximum) into the sockets. 8-9. Thread the light and fan pull chains through the hole in the center of the glass bowl. Then, thread the light pull chain through the hole in the center of the cover plate.
- Page 14 8-21. Once you have uninstalled the light fixture, continue with step 7-6. Male Dummy Terminal Female Dummy Terminal 42834-01 • 01/27/10 • Hunter Fan Company Lower Switch Threaded Rod Steps 8-16 – 8-18 Plug Button Housing Step 8-20...
-
Page 15: Operating And Cleaning Your Ceiling Fan
9 • Operating and Cleaning Your Ceiling Fan 9-1. Turn on electrical power to the fan. 9-2. The fan pull chain controls power to the fan. The pull chain has four settings in sequence: High, Medium, Low and Off. • Pull the chain slowly to change settings. -
Page 16: Troubleshooting
Problem: Lights shut off suddenly 1. Turn the power to the fan off at the wall switch. Wait 30 seconds, then resume power to the fan. 42834-01 • 01/27/10 • Hunter Fan Company 10 •...
