For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: _______________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual.
42800-01 • 01/18/06
Advertisement
Table of Contents
Related Manuals for Hunter 42800-01
Summary of Contents for Hunter 42800-01
- Page 1 For Your Records and Warranty Assistance Model Name: _____________________ Catalog/Model No.: ________________ Serial No.: _______________________ Date Purchased: ___________________ Where Purchased: _________________ For reference also attach your receipt or a copy of your receipt to the manual. 42800-01 • 01/18/06...
-
Page 2: Table Of Contents
• Read this entire manual carefully before beginning installation. Save these instructions. • Use only Hunter replacement parts. • To reduce the risk of personal injury, attach the fan directly to the support structure of the building according to these instructions, and use only the hardware supplied. - Page 3 Consider using Hunter’s optional accessories, including a wall-mounted or remote speed control. To install and use the accessories, follow the instructions included with each product. For quiet and optimum performance of your Hunter fan, use only Hunter speed controls. 42800-01 • 01/18/06 Mounting and Optional Accessories...
-
Page 4: Getting Ready
• Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •... -
Page 5: Installing The Hanger Bracket
CAUTION: To avoid possible electrical shock, before installing your fan, disconnect the power by turning off the circuit breakers to the outlet box and associated wall switch location. If you cannot lock the circuit breakers in the off position, securely fasten a prominent warning device, such as a tag, to the service panel. -
Page 6: Assembling And Hanging The Fan
WARNING: Make sure the square hanger can not rotate in the metal bracket. Failure to do so could result in the fan falling. 3-3. Install two locking screws through the holes in the side of the metal bracket to secure the square hanger. -
Page 7: Wiring The Fan
• e black power wire from the ceiling to the black wire from the 4-4. Push all wires and wire nuts back through the ceiling plate hole into the outlet box. 42800-01 • 01/18/06 4 •Wiring the Fan Step 4-3... -
Page 8: Installing The Motor Housing
Rotate the fan housing to situate the screws in the narrow ends of the keyholes. 5-3. Install the two remaining canopy screws into the holes in the fan housing and into the hanger bracket. Securely tighten all screws. -
Page 9: Assembling The Blades
Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 6-1. Your fan may include blade grommets. If your fan has grommets, insert them by hand into the holes on the blades. 6-2. Attach each blade to a blade iron using three blade assembly screws. -
Page 10: Completing Your Installation With Or Without A Light Fixture
Step 7-4 Hunter Fan Company Your Hunter fan comes with an integrated light fixture assembly and an optional switch housing cap and plug button. is feature gives you the option of installing the fan with OR without the included light fixture. - Page 11 Otherwise, proceed with step 7-8. 7-8. e last installation step when installing the light fixture is to install the glass bowl. See “Installing the Glass Bowl” on page 13 for instructions. 42800-01 • 01/18/06 Connector Steps 7-6 – 7-7 Lower Switch...
- Page 12 7. Install the switch housing cap and plug button to the lower switch housing. Male Dummy Terminal Female Dummy Terminal Hunter Fan Company Lower Switch readed Rod Steps 3 – 5 Plug Button Housing Step 7 42800-01 • 01/18/06...
- Page 13 (You may fi nd the plastic breakaway connector on the end of the extra chain.) 3. read the fan pull chain through the hole in the metal disk. en, thread the fan pull chain through the hole in the center of the glass bowl.
-
Page 14: Operating And Cleaning Your Ceiling Fan
Hunter Fan Company 8-1. Turn on electrical power to the fan. 8-2. e fan pull chain controls power to the fan. e pull chain has four settings in sequence: High, Medium, Low and Off . • Pull the chain slowly to change settings. -
Page 15: Troubleshooting
6. Check and tighten the screws in the switch housing mounting plate and in the upper and lower switch housing. Problem: Excessive wobbling. 1. If your fan wobbles when operating, use the enclosed balancing kit and instructions to balance the fan. 2. Tighten all blade and/or blade iron screws.
