Playback

Playback

General information

Playback can be made in three different ways:
•
Through the video search in the main menu
•
From the live view

Playback screen

Playback is controlled on the control panel:
No. Area
Running playback with date and time
Used to select the camera for feedback
Calendar with recording type (see right)
Control panel with time bar

Using the control panel

The control panel is used for controlling the running play-
back. The symbols have the following meaning:
3 5 7
1 2
4 6
No. Meaning / function
1 Switches audio playback on/off
2 Defines the start and end point of a video for data
backup
3 Previous recording / day
4 Goes back 30 seconds
5, 6 Play or pause for forward / backward playback
7 Stop
8 Advances 30 seconds
9 Fast-forward
25
9 11
12 13
10
8
10 Slow-motion advance
11 Next recording / day
12 Time bar:
•
Click on the time bar with the mouse to con-
tinue playback from another point
•
To start playback from a specific time, click on
the slider and drag it to the required time
13 Recording type
Blue = Continuous recording
Red = Event recording
14 Hides the control panel
15 Exits playback
Note
You can zoom in on the screen image.
•
Right-click in the running playback.
•
Select "Zoom".
•
Zoom mode is now active (see page 21).

Playback through video search

In order to play recorded events, they must first be found.
Open the main menu, then click on "Video Search" in the
"General" tab:
14
15
