MODELS:
ST-HVBI-AUB
ST-HVBILP-AUB
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT USE OR STORE FLAMMABLE
MATERIALS NEAR THIS APPLIANCE.
• DO NOT SPRAY AEROSOLS IN THE VICIN-
ITY OF THIS APPLIANCE WHILE IT IS IN
OPERATION.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11
Owner's Manual
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• DO NOT PLACE ARTICLES ON OR AGAINST THIS
APPLIANCE.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
This is a room sealed appliance and no other ventilation is
required than what is provided.
WARNING! DO NOT modify this appliance.
Installation and Operation
SAI Global
Ref No GSCS20165
AS 4553:2008
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST-HVBI-AUB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heat & Glo ST-HVBI-AUB

Summary of Contents for Heat & Glo ST-HVBI-AUB

  • Page 1 This is a room sealed appliance and no other ventilation is required than what is provided. by a qualifi ed installer, service agency, or the gas supplier. WARNING! DO NOT modify this appliance. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 2 Save this manual for future reference. Heat & Glo, a brand of Hearth & Home Technologies, Inc. 7571 215 Street West, Lakeville, MN 55044 Copyright 2011 • Printed in U.S.A. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 3: Table Of Contents

    3.3 Parts Replacement ..................39 3.4 Adjustments and Replacement Parts ............39 3.5 Maintenance Tasks ..................40 3.6 Troubleshooting ................... 41 4.0 REPLACEMENT PARTS................... 42 Limited Lifetime Warranty ................... 45 Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 4: Installation Instructions

    36-3/16 in. (610m) (121mm) (114mm) (919.3mm) TOP STANDOFFS FLUE COLLAR FLUE COLLAR LOUVER ACCESS DOOR GAS CONTROLS & LABELS GAS LINE ELECTRICAL ACCESS ACCESS Figure 1. Diagram of the ST-HVBI-AU Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 5: Locating The Heater

    Metal Sides or Ends ...13 ....1/2 Top ........64 ....2-1/2 Ceiling* ......787 ....31 * The clearance to the ceiling is measured from the top of the unit, excluding the standoffs (see Figures 1 and 2). Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 6: Framing The Heater

    4 in.) lumber or heavier. 42-5/8 in. 42-1/2 in. 23 in. 35 in. 53-3/4 in. (1.21 m) (1.08 m) (584 mm) (889 mm) (1.37 m) Figure 3. Framing Dimensions Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 7 LP Gas cylinder. A fl ue terminal is considered to be a source of ignition. MINIMUM CLEARANCES REQUIRED FOR BALANCED FLUE TERMINALS OR THE FLUE TERMINALS OF OUTDOOR APPLIANCES Figure 4 Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 8 NOTE: PIPES OVERLAP 32 mm (1-1/4 in.) AT EACH JOINT. Figure 5. DVP-Series Direct Flue Component Specifi cations (127 mm (5 in.) inner pipe / 203 mm (8 in.) outer pipe) Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 9: Flue System Approvals And Installations

    fl ueing confi guration used. STORM COLLAR VERTICAL TERMINATION ROOF FLASHING HORIZONTAL TERMINATION WALL FIRESTOPS PIPE LENGTH 90º ELBOW TERMINATION KITS CEILING FIRESTOP DVP-TVHW DVP-TRAP2 Figure 6. Flue System Components and Termination Kits Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 10 STRAIGHT UP VERTICAL FLUEING V (FT.) 12.2 M MAX. (40 ft.) TERMINATION CAP Figure 7 STRAIGHT OUT HORIZONTAL FLUEING Max. Run 610 mm (24 in.) Figure 8 Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 11 5’ MIN. (1.5 m) 10’ MAX. (3.0 m) V + H = 40’ MAX. (12.2 m) V + H = 40’ MAX. (12.2 m) Figure 10. Flueing with One 90° Elbow Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 12 8’ MAX. (2.4 m) 5’ MIN. (1.5 m) 10’ MAX. (3.0 m) V + V + H = 40’ MAX. (12.2 m) Figure 11. Flueing with Two 90° Elbows Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 13 V + H + H = 40’ MAX. (12.2 m) H + H = 15’ MAX. (4.5 m) H + H = 10’ MAX. (3.0 m) Figure 13. Flueing with Two 90° Elbows Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 14 + H + H = 36’ MAX. (10.9 m) H + H = 12’ MAX. (3.6 m) H + H = 8’ MAX. (2.4 m) Figure 14. Flueing with three 90° elbows Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 15 10’ MAX. (3.0 m) V+ V + H + H = 36’ MAX. (10.9 m) H + H = 10’ MAX. (3.0 m) Figure 15. Flueing with three 90° elbows Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 16 • Overlap pipe slip sections at least 1-1/2 inches (38 mm). • Use pilot holes for screws. • Screws must not exceed one inch long. • Pipe may separate if not properly joined. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 17 For elbows that are changing the fl ue direction, two screws minimum should be put in the outer fl ue at the joint to prevent the elbow from rotating. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 18 12" (305 mm) CHIMNEY HOLE Figure 22. 254 mm x 305 mm Hole and Flue Pipe EXISTING CEILING JOISTS FRAMING MEMBERS CEILING Figure 24. Hole & New Framing Members Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 19 Figure 27. Flueing through the Wall RAFTER • The termination kit should pass through the wall fi restops from the exterior of the building. CEILING CEILING FIRESTOP Figure 26. Attic Firestop Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 20 WARNING: FOLLOWING NATIONAL REG- ULATIONS AND CODES OF PRACTICE FOR MINIMUM CLEARANCES FROM GAS TERMINALS, AND PLACEMENT OF GAS TERMINAL. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 21: Connecting The Gas Supply

    49.4°-53.1° ............1 830 53.1°-56.3° ............2 130 56.3°-59.0° ............2 290 59.0°-60.3° ............2 440 *910 mm minimum in snow regions Figure 30. Minimum Height from Roof to Lowest Discharge Opening Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 22: Ignition System Wiring

    BOX 230 VAC 8K1 WIRE HARNESS TO OPTIONAL COMPONENTS OPTIONAL ON/OFF WALL SWITCH ORANGE GREEN (PILOT) (MAIN) BLACK BATTERY PACK 6V DC (C X 4) BROWN GROUND Figure 32 Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 23: Blower Wiring

    See Figure 31. Figure 33 shows the fan, switches, and fan wiring diagram. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 24: Mantel Clearances

    Figure 36). CEILING 1010 INSIDE EDGE OF DRESS GUARD OPENING DRESS GUARD NOTE: ALL DIMENSIONS ARE SHOWN IN MILLIMETERS Figure 35 HIGH TEMP (300ºF. 150ºC. MIN.) SEAL JOINT Figure 36 Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 25: Log Placement

    LOG #2 (SRV2068-701): Locate log #2 in left front corner of the log grate using bottom grooves for placement. Push log against grate tabs on fi rst and second bars. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 26 Place log #5 on top of fl at spot on log #1 and against the inside of log #2. Be careful not to reposition log #2 when placing this log. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 27 LOG #6 (SRV582-705): Position log #6 on top of the groove in log #3 with the forked end resting on the grate assembly as shown. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 28: Installer Testing

    Figure 37. Pilot Assembly Table 1. Natural Gas Propane Gas Inlet Pressure 1.13 kPa 2.75 kPa Outlet Pressure .80 kPa 2.40 kPa Max. Gas Consumption 44.0 mJ/h 42.5 mJ/h Burner Injector Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 29: Operation Cautions

    • Do not spray aerosols in the vicinity of this appliance while it is in operation. NOTE: THE TIPS OF THE FLAMES SHOULD NEVER HIT THE TOP OF THE FIREBOX. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 30: For Your Safety

    For additional information on operating your Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Final inspection by Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 31: Control Module Operation

    ON. If the ignition command again fails, the module will emit an LED error code, prior to going back into LOCK-OUT mode. Contact your dealer for service if this occurs. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 32: Remote Control Operation

    The RC300AU is approved for interior installation and • Drywall Anchor (2) should not be used in exterior applications. • Screws (2) • Keep remote control out of reach of children. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 33 Figure 42. Remote in Housing Figure 40. Temperature Scale 5. Close the housing door. See Figure 42. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 34 7 min. ON, 12 min. OFF FAN CORD FAN CORD AUX 300 AUX 300 MODULE MODULE LEARN BUTTON Figure 46. Programming RC300AU Figure 45. Plug Fan into AUX300CE Module Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 35 Use the SELECT button to select the current Select feature. Use the UP and DOWN arrows to toggle through the menu functions and value selec- tions in the submenus. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 36 fi replace is turned on. and AUX2 settings will be restored to the previous setting. NOTICE: The system will remember the previous FLAME HEIGHT setting and will automatically adjust after 10 seconds. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 37 NOTICE: No functions will be usable until child lock feature • Locate house circuit breaker for fi replace. is disabled. • Turn off the circuit breaker. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 38: Servicing And Maintenance

    HOT. 7. Visually inspect the fl exible power supply cord; if damaged, contact the service agent for a special replacement cord assembly. Figure 48 Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 39: Removal Of Covers For Servicing

    Remove two pilot bracket retaining screws (see Figure 50.) Slide the burner away from the burner orifi ce. PILOT BRACKET RETAINING SCREWS Figure 50 CAUTION: ALL SCREWS WHICH WERE RE- MOVED MUST BE REPLACED. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 40: Maintenance Tasks

    4. Inspect for corrosion or separation. 5. Verify weather stripping, sealing and fl ashing remains intact. Remote controls 1. Verify operation of remote. 2. Replace batteries in remote transmitters and battery-powered receivers. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 41: Troubleshooting

    fl ame sensing rod. Verify continuity with a multi-meter with ohms set at lowest range. Replace pilot if any damage is detected. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 42: Replacement Parts

    Side Refractory SRV2005-730 Lower Door 2082-042 Dress Guard 2068-040 Glass Door Assembly GLA-6TRXI Burner Assembly N 2082-011 Burner Assembly P 2082-013 Additional service part numbers appear on following page. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 43 14.17 Valve Bracket 2118-104 **Fuse for battery pack can be sourced locally, not a warranty item. Specs are 500mA~10A 3/4” long Additional service part numbers appear on following page. Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 44 050-721 RC300 AU Remote REM300-HNG-AU Touch-Up Paint TUP-GBK-12 Conversion Kits Propane to Natural P2N-STHVBI-AUB Natural to Propane N2P-STHVBI-AUB Pilot Orifi ce N (.020) 2098-520 Pilot Orifi ce P(.0121) 2098-512 Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...

  • Page 45: Limited Lifetime Warranty

    3 years Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645C 12-29-10 Page 1 of 2 Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 46 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645C 12-29-10 Page 2 of 2 Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
  • Page 47 This product may be covered by one or more of the following patents: (United States) 5328356, 5601073, 5613487, 5647340, 5890485, 5941237, 5947112, 5996575, 6006743, 6019099, 6053165, 6145502, 6170481, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7098269, 7258116, 7470729 or other U.S. and foreign patents pending. 2000-945 Heat & Glo • ST-HVBI-AUB • 2082-980 Rev. B • 3/11...
