Page 1: User Guide
ST-POEAF-S16-RM 16 port PoE switch User Guide IMPORTANT This user’s guide contains information on the limitations regarding product use and function and information on the limitations as to liability of the manufacturer. Read the entire guide carefully... - Page 2 The ST-POEAF-S16-RM is Power Source Equipment (PSE) and fully compatible with Powered Devices (PD) that comply with the IEEE 802.3 af PoE standard. The ST-POEAF-S16-RM enables users to attach IEEE802.3 af compliant devices such as wireless Access Points (APS), VOIP phone, IP camera, printer and Network Attached Storage (NAS) directly to the ST-POEAF-S16-RM without requiring additional power on the network.
-
Page 3: Unpacking And Installation
User’s Guide. If any item is found missing or damaged, please contact your salesperson. •Installation: The installation of the ST-POEAF-S16-RM requires the following steps: The surface must support at least 4.5Kg (10 lbs) for the switch. ... -
Page 4: Connecting Network Cables
RJ-45 cable regardless of whether it is a standard or crossover cable. Description •Front Panel: This is the front panel of the ST-POEAF-S16-RM, showing the 16 RJ-45 ports and LED display. Port 1X to 16X : Standard 10/100Mbps Ethernet port. The Switch supports 10Mbps Ethernet or 100Mbps Fast Ethernet and runs both in half and full duplex mode using two pairs of Category 5 or 5e cable. - Page 5 Description •DC Power Jack and Power switch: The DC power jack and power switch are located on the rear panel right side of the ST- POEAF-S16-RM. Use only the supplied AC/DC adaptor. The use of any incompatible adaptor may cause damage to the equipment and void the warranty.
- Page 6 For additional support, please contact SecurityTronix Technical Support: support@securitytronix.com (800) 688-9282 Press “3” for Tech Support, then “2” for CCTV Tech Support.
