- Page 1 INSTALLATION MANUAL© ST-POE-S04-60W 5-Port 10/100 Ethernet PoE Switch Copyright North American Cable Equipment, Inc. v1.0 10/14/10...
-
Page 2: Package Contents
One AC power adaptor One installation manual PRODUCT DESCRIPTION The ST-POE-S04-60W is a 5-port 10/100 Ethernet switch combined with a standard 802.3af 4-port PoE capability. The unit incorporates an external 48VDC power adaptor. Each of the four PoE Ethernet ports can provide 15.4 watts of power as well as 10/100Mbps data transmission over as CAT 5/ 5e /6 cables. -
Page 3: Specifications
SPECIFICATIONS ST-POE-S04-60W Specifications (Typical) IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet 1. Standard IEEE 802.3x Full Duplex Flow Control IEEE 802.3af Power Over Ethernet 2. Protocol CSMA/CD Ethernet: 10Mbps (half-duplex), 20Mbps (full-duplex) 3. Data Transfer Rate Fast Ethernet: 100Mbps (half-duplex), 200Mbps (full-duplex) 10BASE-T: 2-pair UTP CAT 3, 4, 5 up to 328 feet 4. - Page 4 3. HARDWARE CONNECTIONS The unit should be installed within 6 feet of the AC power outlet and on a surface capable of supporting the device’s 2.8 lbs weight. Objects are not to be placed on the device and there must be sufficient space and ventilation for proper heat dissipation. Rear Panel Description The rear panel consists of a 48V DC power jack and 5 RJ-45 ports.
-
Page 5: Troubleshooting
Power LED LED “On”: Power is on; LED “OFF”: Power is off LINE/ACT LED “On”: Specific port is linked and active. LED “OFF”: Specific port is not connected or inactive 10/100M LED “On”: Specific port is connected to a 10/100Mbps Ethernet Network LED “Blinking”: Specific port is transmitting or receiving data LED “Off”: No link to that port PoE (1 through 4)
