LIP-8008E

User Guide

Please read this manual carefully before
operating Phone. Retain it for future reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iPECS LIP-8008E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG-Ericsson iPECS LIP-8008E

Summary of Contents for LG-Ericsson iPECS LIP-8008E

  • Page 1: User Guide

    LIP-8008E User Guide Please read this manual carefully before operating Phone. Retain it for future reference...

  • Page 2: Revision History

    LIP-8008E User Guide Revision History Issue Date Remark Mar. 2012 Initial Release Oct. 2012 Changed CI to Ericsson-LG Disposal of your old appliance 1. When the crossed-out wheeled bin symbol is attached to a product, it means the product is covered by the European Directive 2002/96/EC.

  • Page 3: Important Safety Information

    LIP-8008E User Guide Important Safety Information To prevent unexpected danger or damage please read this information before installing or attempting to repair you phone. Warning and Caution information is provided to alert the consumer of known dangers: Warning: To reduce the possibility of electric shock, do not expose your phone to high humidity areas, such as a bathroom, swimming area, etc.

  • Page 4: European Union Declarations Of Conformity

    LIP-8008E User Guide [EU] European Union Declarations of Conformity Ericsson-LG Co., Ltd. declare that the equipment specified in this document bearing the “ CE” mark conforms to the European Union Radio and Telecommunications Terminal Equipment Directive(R&TTE 1999/5/EC), including the Electromagnetic Compatibility Directive(2004/108/EC) and Low Voltage Directive(2006/95/EC).

  • Page 5: Table Of Contents

    LIP-8008E User Guide TABLE OF CONTENTS ......................... 1 1. I NTRODUCTION ....................................1 1.1 G ENERAL ............................... 1 1.2 F EATURE NFORMATION ..............................1 1.3 F EATURE ROUPINGS ....................2 PECS LIP-8008E P HONE ESCRIPTION ........................3 1.5 LIP-8008E P HONE NSTALLATION 1.5.1...
  • Page 6 LIP-8008E User Guide ......................29 4. C ANDLING .......... 29 4.1 C RANSFER ENDING A CALL TO A DIFFERENT DESTINATION ................29 4.2 C LACING A CALL IN A WAITING STATE ................30 4.3 B ROKER WITCHING BETWEEN TWO CALLS ..................

  • Page 7: Introduction

    LIP-8008E User Guide 1. Introduction 1. Introduction 1.1 General Your telephone is connected to an advanced-technology, highly-versatile, fully-featured telecom system designed to make office communications easy and productive. Employing state-of-the-art Voice over Internet Protocol (VoIP) technology, voice and data converge on a single IP packet network.

  • Page 8: Ipecs Lip-8008E Phone Description

    LIP-8008E User Guide 1.4 iPECS LIP-8008E Phone Description The iPECS LIP-8008E Phone incorporates the latest in VoIP technology intended basic communications (ex., a lobby or limited use phone). The following image shows the LIP-8008E. LIP-8008E Front and Back Features are generally accessed using programmed fixed, or flexible buttons, dial pad buttons, or dial codes entered from the dial pad.

  • Page 9: Lip-8008E Phone Installation

    LIP-8008E User Guide DND – Blocks all incoming calls; red LED illuminates. Speed – Access speed dialing, speed programming. Vol   – Adjusts volume for ringing, headset, and speakerphone; adjusts LCD brightness (in idle state). Trans/PGM –Call transfer, or programming mode. Hold/Save –...

  • Page 10: Wiring Connectors

    LIP-8008E User Guide iPECS LIP-8008E Connections 1.5.1 Wiring Connectors The LIP-8008E has a two Ethernet ports one is connected to the LAN using a RJ-45 plug terminated category 5 cable supplied with the Phone, the other can be connected to a desktop PC. Using the cable, one RJ-45 plug is inserted into the "LAN"...

  • Page 11: Wall Mount

    LIP-8008E User Guide 1.5.3 Wall Mount The LIP-8000 series phones can be wall mounted as needed. The following instructions detail how to perform a wall mount installation: • Mark and drill two (2) 7mm holes for plastic wall anchors. • Insert the two (2) anchors into the holes and insert and tighten each screw leaving about 2.5 mm (1/8-inch) of the screw exposed.
  • Page 12 LIP-8008E User Guide LIP-8000 DSS Installation LIP-8000 DSS Installation (12DSS + 48DSS)

  • Page 13: Using A Serial Dss

    LIP-8008E User Guide LIP-8000 DSS Installation (12DSS + 12LSS) 1.7 Using a Serial DSS The LIP-8012ESS, LIP-8012LSS, and LIP-8048DSS can be connected with the LIP-8012E or LIP-8024E using the RS-232 cable. Be sure to verify the serial DSS and LSS capacities with the iPECS System to ensure usability (refer to iPECS Manual).
  • Page 14 LIP-8008E User Guide LIP-8012LDSS LIP-8012ESS LIP-8048DSS...
  • Page 15 LIP-8008E User Guide In iPECS-LIK To use a Serial DSS: • Verify the Station has Serial DSS Usage authority (Admin PGM111-Flex21), • Verify the DSS power is OFF (LIP-8048DSS only), • Power-OFF the phone, • Connect the serial DSS to the phone, •...

  • Page 16: Receiving Calls

    LIP-8008E User Guide 2. Receiving Calls 2. Receiving 2.1 Answering a Call While Idle Calls There basic types incoming calls; internal/external calls, Intercom Voice Announce calls, and Hold recalls. Your phone assigned Ringing Line Preference; in this case, calls that ring are answered by lifting the handset.

  • Page 17: Differential Ring Signals

    LIP-8008E User Guide of the existing call, as an indication of another call waiting. While busy, certain stations can activate Voice-Over to your phone. When used audio is received from both the active call and the Voice Over announcement. Respond to any of these Off-hook Signals by: placing the existing call on Hold and responding to the new incoming call, activating One-time DND, sending a Silent Text Message, or ignoring the new call.
  • Page 18 LIP-8008E User Guide In iPECS-LIK To download a Ring Tone from System memory: • Press TRANS • Dial 1 for Ring Tones, • Dial 5 for Ring Tone download, • Dial the phone’s memory location to receive the tone (5-8), •...

  • Page 19: Answering Calls At Night

    LIP-8008E User Guide 2.4 Answering Calls at Night In the Night mode, Loud Bell Control may be used to send ring signals to external bells. You may answer these calls with Universal Night Answer (UNA). To answer a call ringing during night mode: •...

  • Page 20: Forwarding Calls

    LIP-8008E User Guide The Attendants and Secretary may be able to activate DND Override and Intrude on an active call. Attendants may also cancel DND at other stations. To toggle DND ON and OFF: • Press the DND button. 2.7 Forwarding Calls 2.7.1 Forwarding calls to another station or Voice Mail Incoming calls may be diverted to other resources of the system.

  • Page 21: Forwarding Calls To An External Number

    LIP-8008E User Guide To activate Call Forward from your phone to another phone or internal system resource: • Lift the handset, • Press FWD soft button , • Dial the type of forward code 1-4, • Dial the destination number. To deactivate Call Forward from your phone: •...
  • Page 22 LIP-8008E User Guide When you forward calls from a different station or a remote location, may need to enter your Authorization Code. In addition, from a remote location, you must access the system through a DISA enabled CO line. In IPECS-LIK, iPECS SBG-1000 To activate Call Forward, Off Premise (forward to an external number) from your phone: •...

  • Page 23: Forwarding Callers To A Text Message

    LIP-8008E User Guide In iPECS-MG To activate Call Forward, Off Premise (forward to an external number) from your phone: • Lift the handset, • Dial 554 (Call Forward Register Feature Code), • Dial the type of Forward code (1-4), • Dial Telephone number, •...
  • Page 24 LIP-8008E User Guide Message 04: OUT OF OFFICE RETURN AT DATE mm:dd Message 05: OUT OF OFFICE RETURN UNKNOWN Message 06: CALL (enter up to 17 digits) Message 07: IN OFFICE STA xxxx Message 08: IN MEETING RETURN AT TIME hh:mm Message 09: AT HOME Message 10:...
  • Page 25 LIP-8008E User Guide In iPECS-LIK To activate Custom or Pre-defined Message Forward: • Lift the handset, • Press TRANS • Dial User Program feature code 51, • Dial the two-digit text Message code (00-20), • Dial any auxiliary input for messages 01-04 and 06-08, •...
  • Page 26 LIP-8008E User Guide In iPECS-MG To activate Custom or Pre-Defined Message Forward: • Press TRANS • Dial User Program feature code 41, • Dial the one-digit text Message code (0-9), • Dial any auxiliary input for messages 1-4 and 6-8, •...

  • Page 27: Placing Calls

    LIP-8008E User Guide 3. Placing Calls 3. Placing Calls 3.1 Internal Calls You can place calls to other stations in the system over the Intercom. The call will ring, or for an ICM Voice Announce call, a splash tone will be heard. Ring or Voice Announce is normally determined by settings at the called station but you may change this by dialing ‘#’...

  • Page 28: To Leave A Message Wait

    LIP-8008E User Guide If you are the Attendant or Secretary, you may activate Intrusion. You may also use Step Call; dial the next station by dialing just the last digit of the Intercom number. To Camp-On (wait off-hook) for a busy station: •...
  • Page 29 LIP-8008E User Guide 88 + Line number (01-80 for iPECS-MG100, or 001-240 for iPECS-MG300). CO/IP Group access 801-805 for iPECS SBG-1000, 801-820 for iPECS- 50 & 100, 801-872 for iPECS-300 & 600, or 8900`-89100 for iPECS-1200 801-824 for iPECS-MG100, or 801-872 for iPECS- MG300 Any CO/IP Line access When dialing on a CO line, which uses pulse style...

  • Page 30: Waiting For The Next Available Co/Ip Line

    LIP-8008E User Guide To place an external call: • Lift the handset, • Select/dial the CO/IP line/group, • Dial the desired number. 3.2.2 Waiting for the next available CO/IP line If all the lines connected to your system are busy, you will receive an All Trunks Busy signal.

  • Page 31: To Disable Dialing From Your Phone

    LIP-8008E User Guide In iPECS-MG To enter an Account Code before the call: • Lift the handset, • Dial 550, • Dial the Account Code (1-12 digits), • Press *, Intercom dial tone is heard, • Place the CO/IP call as normal. 3.2.4 To disable dialing from your phone You can temporarily ‘Lock’...

  • Page 32: Using Automated Dialing

    LIP-8008E User Guide 3.3 Using Automated Dialing 3.3.1 Using Last Number Redial (LNR) The last number dialed on an external call is automatically saved in the Last Number Redial (LNR) buffer. In iPECS-LIK, iPECS SBG-1000 To dial the Last Number for an external call: •...

  • Page 33: Using And Entering Station Speed Dial Numbers

    LIP-8008E User Guide 2000-4999). The iPECS-600 system has memory allocated for 6000 System Speed Dial numbers (bins 2000-7999). The iPECS-1200 system has memory allocated for 12000 System Speed Dial numbers (bins 20000-31999). The iPECS-MG100 system has memory allocated for 1000 System Speed Dial numbers (bins 2000-2999).
  • Page 34 LIP-8008E User Guide ‘*’ not as 1 digit—Dial Pulse to Tone Switchover, the system will switch from pulse to tone dialing. When entering a Speed Dial, a 16 character name may be associated with the number for Dial by Name. To place a call using Station Speed Dial: •...

  • Page 35: Call Handling

    LIP-8008E User Guide 4. Call Handling 4. Call 4.1 Call Transfer: Sending a call to a different destination Handling You can send an active call to another station or other resource of the system, using Call Transfer. You can screen the transfer with the receiving party (Screened Call Transfer) or complete the transfer without screening (Unscreened Call Transfer).

  • Page 36: Broker Call: Switching Between Two Calls

    LIP-8008E User Guide 4.3 Broker Call: Switching between two calls You may switch between the active call and a call on Hold, placing the active call on Hold acting as a broker between two or more parties, Broker Call. iPECS Phone users may ‘broker’...

  • Page 37: Setting Up A Conference Room

    LIP-8008E User Guide To retrieve the Conference from Hold: • Press the button. CONF To establish an Unsupervised Conference: • Establish conference with two external parties, • Press the button. CONF • Hand-up handset. • To retrieve an Unsupervised Conference: •...

  • Page 38: Call Park: Placing A Call On Hold To Page

    LIP-8008E User Guide In iPECS-MG To set-up a Conference Room: • Press the button, TRANS • Dial 54 to create a Conference Room, • Dial the desired Conference Room number (571-579), • If desired enter a password for the Conference Room (up to 12 digits), •...
  • Page 39 LIP-8008E User Guide In iPECS-MG To park an active external call: • Press TRANS • Dial the Park Orbit (541), • Dial the Park number (00-49) • Return to idle. To retrieve a parked call: • Lift the handset, • Dial the Park Orbit (541), •...

  • Page 40: Retrieving & Responding To Messages

    LIP-8008E User Guide 5. Retrieving 5. Retrieving & Responding to Messages & Responding 5.1 Responding to a Station Message Waiting Indication to Messages Another station can leave a Station Message Waiting indication when you do not answer or your phone is in DND.
  • Page 41 LIP-8008E User Guide To retrieve Voice Mail locally: • Press CALL BACK • After the prompt enter your station number and password, • Dial desired option codes, • At completion of session, hang-up to return to idle. To access Voice Mail Box from a Remote Location: •...

  • Page 42: Remote System Access

    LIP-8008E User Guide 6. Remote 6. Remote System Access System 6.1 Direct Inward System Access (DISA) Access DISA (Direct Inward System Access) allows remote users to gain access to the system’s resources (remote users may be required to enter an Authorization Code). The system will recognize remote user dialed inputs (call other stations, place calls over CO/IP lines, review voice mails, etc).
  • Page 43 LIP-8008E User Guide NOTE—The mobile extension may reconnect to the transfer by pressing the # key. In iPECS-LIK, iPECS SBG-1000 To register a mobile phone number: (iPECS-LIK) • Press the button, TRANS • Dial 37. • Dial the mobile phone number. •...
  • Page 44 LIP-8008E User Guide In iPECS-MG To register a mobile phone number: • Press the button, TRANS • Dial 51, • Select Mobile Index 1 or 2, • 1 to activate, 0 to deactivate, • Press the button. HOLD SAVE To activate a registered mobile phone from the user’s station: •...

  • Page 45: Misc. Features

    LIP-8008E User Guide 7. Misc. 7. Misc. Features Features 7.1 Background Music and Music on Hold (iPECS-LIK) Two audio sources can be connected to the system. These sources or an internal source provide input for Background Music (BGM) and Music On Hold (MOH). In addition, a recorded message from the VMIM can be used.
  • Page 46 LIP-8008E User Guide External Page Zones 545-546 External All Call Page 548 All Call Page In iPECS-MG, Page Zone codes are: Internal Page Zones : 543 + Zone No(01~15) (iPECS-MG100) 543 + Zone No(01~30) (iPECS-MG300) Internal All Call Page 543 + 00 External Page Zones 548 All Call Page If the desired Page Zone is busy, the User can elect to...

  • Page 47: Push-To-Talk (Ptt) Page

    LIP-8008E User Guide 7.3 Push-To-Talk (PTT) Page iPECS Phones can be assigned as a member of one or more of the system’s nine Push-To-Talk (PTT) page groups. Users separately log-in or log-out of any one or all PTT groups to which the phone is assigned. Once logged place receive...

  • Page 48: Alarm/Door Bell

    LIP-8008E User Guide 7.5 Alarm/Door Bell The system can monitor external Alarm or Door Bell contacts: Alarm Monitor—should the external contact activate, a unique Alarm Ring signal and LCD display may be received. To restart the monitor circuit, the external contacts must be deactivated and the Alarm Ring signal terminated.

  • Page 49: Contrast (Ipecs-Lik)

    LIP-8008E User Guide ICM Signaling Mode (Handsfree/Tone/Privacy) Station IP Address Station Mac Address Number of messages x (x: number of all message waiting) Wake-Up Time (hh:mm) Do Not Disturb Forwarded to station xxx Forwarded to speed bin xxx Queued CO/IP line xxx Locked (Temporary COS) COS x NOTE—Only activated features are announced.

  • Page 50: Network Config

    LIP-8008E User Guide 7.9 Network Config. The user can review the current network configuration or modify a new phone network configuration. To access Network Config. Settings: • Press T /PGM button and Dial 78(iPECS-LIK)/38(iPECS RANS SBG-1000)/80(iPECS-MG), • Enter the password (default=147*), the following will display: •...

  • Page 51: Pbx, Centrex & Isdn

    LIP-8008E User Guide 8. PBX, 8. PBX, Centrex & ISDN Centrex & 8.1 Access PBX or Centrex ISDN The iPECS has been designed to operate with a host PBX system or Centrex services from your service provider. The iPECS connects to a host with analog CO lines.

  • Page 52: Activating Isdn Caller Id Restriction

    LIP-8008E User Guide To deactivate Keypad Facility operation: • Press K EYPAD ACILITY • • Press a Feature or Flex button. 8.2.2 Activating ISDN Caller ID restriction iPECS Phone users can restrict the transmission of Caller ID to the receiving phone (may be a subscription service of your carrier).

  • Page 53: Set Features & Flex Buttons

    LIP-8008E User Guide 9. Set 9. Set Features & Flex Buttons Features & 9.1 Entering Station Program Data Flex Buttons A special code set is available for iPECS Phone users to assign certain attributes such as Authorization Codes (Passwords). After entering the User Program mode, dial the codes to select the attribute and setting.

  • Page 54: Network Configuration

    LIP-8008E User Guide 9.3 Network configuration You many review the current network configuration or modify a new phone network configuration. To access Network settings: • Press button and dial 78(iPECS-LIK)/38(iPECS TRANS SBG-1000)/80(iPECS-MG), • Enter the password (default=147*); the following will display: •...
  • Page 55 LIP-8008E User Guide To set LLDP: • ▲▼ buttons to locate the In Network Config. Menu, use 802.1x configuration screen (shown), • LLDP? • [ENABLED] – CHANGE [#] • Enable in LLDP? menu and press the Hold/Save button. To configure 802.1x: •...

  • Page 56: Appendixa Flexible Numbering Plan

    LIP-8008E User Guide Appendix A Flexible Numbering Plan In iPECS-LIK, iPECS SBG-1000 Feature iPECS iPECS iPECS iPECS iPECS iPECS -100 -300 -600 -1200 SBG- 1000 Intercom Call 100 - 100 - 100 - 1000 - 1000 - 10-33 1599 2199 CO/IP Group Access 801 –...
  • Page 57 LIP-8008E User Guide Feature iPECS-LIK iPECS SBG- Remark 1000 Speed Dial Programming SLT use only Message Wait/Callback SLT use only Enable Message Wait/Callback SLT use only Return Speed Dial Access SLT use only Cancel DND/FWD SLT use only CO System Hold SLT use only Program Mode Access SLT use only...
  • Page 58 LIP-8008E User Guide Feature iPECS-LIK iPECS SBG- Remark 1000 Attendant Call VM Message Wait Enabled VM Message Wait Disable MCID Request Unsupervised Conference extend code PTT Group Login/Logout In iPECS-MG 1) Basic Number Code Name Remark 100 ~ 4xx Station Number CO Group Access Code 801 ~ 872(MG-300) 801 ~ 824(MG-100)
  • Page 59 LIP-8008E User Guide Feature Name Code Remark Attendant Page Auto Answer Internal Page Answer (Meet-Me Page) External Page Internal-External Page All Call Forward Register 554 + Type + Destination Pilot Hunt Call Forward 514 + Type + Register Destination Pilot Hunt Call Forward Cancel DND Status Change DND Delete...
  • Page 60 LIP-8008E User Guide Feature Name Code Remark 01 ~ 80 : MG- 100) VM MWI Enable VM MWI Cancel MCID Request Unsupervised Conf Extend PTT Group Access 524 + (0~9,*) 0 ~ 9: PTT Group # *: Log out Hot Desk Log In/Log out Name Register Create Conf Room 527 + Conf.
  • Page 61 LIP-8008E User Guide Feature Name Code Remark Mobile CLI Register Mobile Access CCR Access CCR Access And Drop System Hold Return Held CO Sys Memo DISA Tone Service All Feature Cancel Add Conf Member System Alarm Reset Fault Alarm Reset Door Open Keypad Facility T-Net Log-In/Out...

  • Page 62: Appendixb User Program Codes

    LIP-8008E User Guide Appendix B User Program Codes In iPECS-LIK Code Function Remarks Enblock Mode Dialing 11 x Differential Ring, Intercom Select Ring Tone 1-8 12 x Differential Ring, CO/IP line Select Ring Tone 1-8 Select ICM Signal mode, 13 x Intercom Answer Mode 1: HF, 2: TONE, 3: Privacy 14 x...
  • Page 63 LIP-8008E User Guide Code Function Remarks Display Phone IP Address Change Phone IP Address Display Phone MAC IP Address Network Configuration Display Phone Version Assign R Button Requires VSF/External SMDI VM ECORD Assign ISDN CLIR Button ISDN COLR Button Assign A Button CCOUNT Assign LOOP Button...
  • Page 64 LIP-8008E User Guide Code Function Remarks Display Phone IP Address May require Authorization code Display Phone MAC IP Address Display Phone Version Network Configuration Forced FWD to Destination Call Log Display CLIR Service COLR Service Assign Button LOOP Assign Button CALL BACK Assign Button...
  • Page 65 LIP-8008E User Guide Code Function Remarks 41 + MSG 0-9, MSG Set Pre-defined Message. number [xx] *: User Custom # Deactivation Create a Station User Message Send SMS Message LIP Series/LDP6000 Series Receive SMS Message LIP Series/LDP6000 Series 51 + x Activate a mobile phone X=1-2 52 + x...

  • Page 66: Appendixc Useful Information : Open Source Software Notice

    LIP-8008E User Guide Appendix C Useful Information : Open Source Software Notice Open Source Software Notice This following GPL (General Public License) software used in this product are subject to the GPL License Agreements. You can obtain a copy of the GPL licenses from Ericsson-LG Web Site (http://www.ericssonlg.com).
