Page 1: User Manual
XTZ 93 WMT Shielded Bookshelf speaker/Center speaker User manual © 2008 XTZ AB , www.xtz.se... -
Page 2: Table Of Contents
Table of Contents Page Introduction About 93 WMT Shielded/ About XTZ Technical presentation Preparations Practice of sound / Installing and placing tips Mounting and Connecting tips Sound settings Technical specifications Service & Support - 2 -... -
Page 3: Introduction
(See further under the heading of Support on the last page of this manual). About 93 WMT Shielded XTZ 93 WMT Shielded is a bookshelf speaker that can be used as either a center/frontspeaker (on a stand for example) or a satellite speaker. -
Page 4: Technical Presentation
Technical presentation Cabinet design The cabinet is constructed with a narrow baffle - not only an aesthetically neat shape but also an advantage in terms of sonics since you have a more stable baffle which effectively muffles resonances in the cabinet. The cabinet is made in 25mm MDF board, which has good sonic qualities. -
Page 5: Preparations
Preparations Carefully unpack the speaker, and pay attention so you Unpacking don't break anything. If possible, save the carton box for future transportations. If there should be damage on the loudspeaker, please contact your retailer. Accessories 1 pc bass reflex plug User manual Logotype Rubber feet... - Page 6 Amplification of bass A loudspeaker that is placed near a wall, ceiling or floor will be amplified in the lower frequencies in a sometimes frequencies not desirable way (since it may lead to an indistinct sound recreation). This amplification becomes even more obvious if the loudspeaker is placed near a corner.
-
Page 7: Mounting And Connecting Tips
It takes about 50 to 100 hour of initial playing time, for the driver to sound optimal. During this time, time the speaker may be used normally. 93 WMT Shielded is constructed to play lying down Placing or standing up. The rubber feet are not mounted and can be mounted on either side. -
Page 8: Sound Settings
Mechanical taste, so please have patience when trying on the XTZ 93 WMT shielded. adjustment of the out your preferred setting. Also the treble level may be adjusted, which allows... -
Page 9: Technical Specifications
Technical specifications Construction type 2-way, Bass reflex cabinet that may be set as a closed box. The cabinet can be lying down or standing up The treble level is adjustable in two different levels Dimensions 220 x 370 x 312 mm (W x H x D) Weight 11,7 kg Magnetically... -
Page 10: Service & Support
Service & support We apply "do-it-yourself" service on all XTZ service, products "Do-It-Yourself"- constructed and produced using common products. service technology, so that basically most people If you by yourself are able to find out what part of are able to "unscrew" the loudspeaker the loudspeaker is defective, you are fully allowed using common tools.
