Summarization of Contents
About XTZ
XTZ Philosophy and Goal
Explains XTZ's commitment to natural sound and providing the best value for money through cost-effective production and quality.
Contact Information
Provides website and email address for XTZ contact and support.
Technical Presentation
Cabinet Design and Construction
Details the narrow baffle, curved sides, MDF board, and internal bracing for acoustic performance and stability.
Tweeter Driver Specifications
Describes the ribbon tweeter, its super light cone, sandwich construction, neodymium magnets, and high-frequency capability.
Woofer/Midrange Driver Details
Explains the selected 6.5" Seas Excel magnesium driver, its stiff cone, high-flow basket, and effective resonance reduction.
Woofer Driver Specifications
Details the 6.5" Seas coated paper driver, its lightweight and stiff cone, high-flow basket, and strong magnet system.
Crossover and Binding Post System
Describes the -12/18 dB crossover, gold-plated bi-wiring terminals, and available coupling modes for signal routing.
Preparations
Unpacking and Handling
Instructions for carefully unpacking the speaker, saving the box for future transport, and contacting the retailer for damages.
Included Accessories
Lists the accessories provided with the speaker, including bass reflex plugs, user manual, and loops for level adjustment.
Practice of sound / Installation and placement tips
Room Acoustics and Sound Environment
Guidance on room acoustics, minimizing reflections, managing bass amplification, furniture impact, and ideal room dimensions.
Loudspeaker and Subwoofer Placement
Advice on optimal loudspeaker and subwoofer placement to achieve the best sound and avoid phase errors.
Cables, Speaker Setup, and Subwoofer Configuration
Recommendations for cable length, front speaker placement angles, and advantages of using two subwoofers for improved sound.
Mounting and Connecting tips
Mounting Alternatives and Wall Proximity
Discusses standing placement near walls and the influence of rear/side walls on bass characteristics.
Correct Phase Connection and Overload Risk
Emphasizes correct phase connection and warns about the risk of overloading drivers and amplifiers at high loads.
Initial Playing Time for Optimal Sound
Notes that 50-100 hours of initial playing time are needed for drivers to reach optimal performance.
Sound settings
Room Tuning and Bass Response
Explains using bass plugs to adjust bass reflex gates for different bass modes and levels, adapting to room acoustics.
Treble Level Adjustment
Details four modes for adjusting the treble range to perfectly alter the sonic to fit the room, equipment, and taste.
Bass Level Adjustment
Details four modes for adjusting the bass range to achieve a neutral, deep, or quick bass response as desired.
Binding Post and Biwiring Configuration
Explains terminal types, bi-wiring, and signal routing for different speaker connections like tweeter, midrange, or woofer only.
Technical specifications
Construction and Physical Specifications
Covers construction type (2 1/2-way), dimensions, weight, magnetic shielding, and impedance.
Performance and Driver Specifications
Details efficiency, power handling, and specifications for tweeter and woofer/midrange drivers.
Connection and Tuning Options
Outlines binding post types, bi-wiring capability, bass reflex modes, and bass/treble level adjustments.
Service & support
DIY Service and Troubleshooting
Explains the 'do-it-yourself' service approach, allowing users to send defective parts for exchange and contact for help.
Warranty Claims and Shipping Procedures
Details warranty application for manufacturing defects, handling of self-caused damages, and packing for shipping.
Customer Support and Contact Information
Provides contact methods for installation advice, technical support via email, and general inquiries.
